神钢零件查询(MD180LC) - EXCAVATOR ASN YG0647 (1/80-12/06) (08-010) - BUZZER ASSY, BACK Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
150 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N4097F1 | [1] | BUZZER ASSY, BACK | |
| 1. | 2416P8798 | [1] | BRACKET | KOB |
| 2. | 2416P8797 | [1] | BRACKET BRACKET | BRACKET BRACKET |
| 3. | 2479Z955 | [2] | LIMIT SWITCH | KOB Superseded by part number: 2479Z700 |
| 4. | 2447R102 | [1] | BUZZER | KOB |
| 5. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 6. | ZW16X10000 | [2] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 7. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 8. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 9. | ZS18C06020 | [2] | SCREW,Hex, M6 x 20mm | KOBM06x1.0x20mm |
| 10. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 11. | ZW26X06000 | [2] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 12. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 13. | 2479Z1057 | [1] | HARNESS HARNESS | HARNESS HARNESS |
