纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[10]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
713 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF21C00016F1 | [1] | | |
| 2. | LF21C01154F1 | [1] | COVER ASSY | KOB |
| 3. | LF21C01155P1 | [1] | TOOL BOX | KOB |
| 4. | LF21C01090P2 | [1] | COVER | KOB |
| 5. | LF21C01112F1 | [1] | HINGE | KOB |
| 6. | PM21C01268F1 | [1] | LOCK | KOB |
| 7. | YR22C01025P2 | [1] | LOCK | KOB |
| 8. | PM21C01269P1 | [1] | PLATE | KOB |
| 9. | YN21C02821P1 | [1] | STAY | KOB |
| 10. | ZW16P06000 | [1] | WASHER | KOB |
| 11. | 2419R9D1 | [1] | COTTER PIN | KOB |
| 12. | ZM73C12020 | [2] | BOLT,M12x20mm - Course Thread | KOBSems |
| 13. | YJ21C01103D9 | [1] | WEATHERSTRIP | KOB |
| 14. | PM22C01013DL | [1] | WEATHERSTRIP | KOB |
| 15. | YJ21C01103D7 | [1] | WEATHERSTRIP | KOB |
| 16. | YR21C01168DH | [1] | WEATHERSEAL STRIP | KOB |
| 17. | LF21C01168P1 | [1] | WASHER | KOB |
| 18. | LF21C01170P1 | [1] | COVER | KOB |
| 19. | LF21C01125F1 | [1] | COVER ASSY | KOB |
| 20. | LF21C01163P2 | [1] | COVER | KOB |
| 21. | PH21C01136DB | [1] | WEATHERSTRIP | KOB |
| 22. | YT21C01039DC | [1] | WEATHERSTRIP | KOB |
| 23. | YR21C01168D1 | [1] | WEATHERSTRIP | KOB |
| 24. | YR21C01168DF | [1] | WEATHERSTRIP | KOB |
| 25. | YT21C01164D5 | [1] | WEATHERSTRIP | KOB |
| 26. | ZM73C12025 | [16] | BOLT,M12x25mm - Course Thread | KOBSems |
| 27. | ZM73C12040 | [1] | BOLT,M12x40mm - Course Thread | KOBSems |
