纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-069[09]) - GUARD INSTALLATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
123 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LF21C00010F1 | [1] | | |
| 2. | LF21C01161F1 | [1] | COVER | KOBL/H |
| 3. | LF21C01162P2 | [1] | COVER | KOB |
| 4. | YF21C01331P1 | [2] | HINGE | KOB |
| 5. | PM21C01268F1 | [1] | LOCK | KOB |
| 6. | YR22C01025P2 | [1] | LOCK | KOB |
| 7. | PM21C01269P1 | [1] | PLATE | KOB |
| 8. | YF21C01566P1 | [1] | LOCK | KOB |
| 9. | PH22C01023P1 | [4] | BOLT | KOB |
| 10. | ZW16H05000 | [4] | WASHER | KOB |
| 11. | ZW26X05000 | [4] | LOCK WASHER | KOBLock |
| 12. | ZN18C05004 | [4] | NUT | KOB |
| 13. | YR21C01123P1 | [1] | COLLAR | KOBClip |
| 14. | YF21C01335P1 | [1] | STAY | KOB |
| 15. | YT21C01039DU | [1] | WEATHERSTRIP | KOB |
| 16. | YT21C01886P1 | [1] | RUBBER SEAL | KOB |
| 17. | YT21C01937P1 | [1] | RUBBER SLEEVE | KOB |
| 18. | YT21C01887P1 | [1] | RUBBER SEAL | KOB |
| 19. | YT21C01689F1 | [1] | COVER | KOBR/H |
| 20. | YT21C01919P1 | [1] | COVER | KOB |
| 33. | YT21C01924P1 | [1] | INSULATION | KOB |
| 34. | YT21C01923P2 | [1] | INSULATION | KOB |
| 38. | YF21C01782D1 | [4] | SHIM | KOB(2.3) |
| 39. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOBSems |
| 40. | YF21C01551P1 | [2] | STRIKER PLATE | KOB Superseded by part number: YF21C01802P1 |
| 41. | YN21C03212P1 | [4] | STOP | KOB |
| 42. | ZN18F10008 | [4] | NUT | KOB |
