凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.510.02) - SWITCH UNIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
368 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87588879
|
[1] |
SWITCH
|
SAS
unit, auxiliary
|
| 2. |
87651139
|
[1] |
BRACKET
|
SAS
switch mount
|
| 3. |
435430A1
|
[1] |
U-BOLT
|
CAS
ur 1/4" x 1" w x 1 3/4" d 1" thread
|
| 4. |
80701
|
[2] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 5. |
280129
|
[2] |
NUT,1/4"-20
|
NH
|
| 6. |
84305559
|
[2] |
SCREW,Pan, #6 - 32 x 1/4"
|
SAS
machine #6-32 x 1/4"
|
| 7. |
87276
|
[2] |
LOCK WASHER,3.58mm ID x 6.35mm OD x 0.79mm Thk
|
GI
|
| 8. |
51200015
|
[6] |
SWITCH
|
FLX
toggle spdt on off on pwb
|
| 9. |
87508176
|
[1] |
TOGGLE SWITCH
|
SAS
spdt on off mom pw Superseded by part number: 87681163
|
