纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-073[00]) - COVER ASSEMBLY, UNDER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
980 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF24C00005F1 | [1] | Under | |
| 1. | LF24C01010P1 | [1] | COVER | KOB |
| 2. | LF24C01011P1 | [1] | COVER | KOB |
| 3. | YT24C01071P1 | [1] | COVER | KOB |
| 4. | YT24C01045P1 | [1] | COVER | KOB |
| 5. | YT24C01073P1 | [1] | COVER | KOB |
| 6. | YT24C01042P1 | [1] | COVER | KOB |
| 7. | ZM73C12030 | [38] | BOLT,M12x30mm - Course Thread | KOBSems |
| 8. | LF24C01007P2 | [1] | COVER | KOB |
| 9. | LF24C01008P1 | [1] | COVER | KOB |
