纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-078[00]) - ELECTRICAL ASSEMBLY, UPPER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
999 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT03E00009F1 | [1] | Upp. | |
| 1. | YN24S00008F1 | [1] | RELAY | KOBBattery |
| 2. | LC53S00001D2 | [1] | HORN,350Hz | KOB |
| 3. | ZM73C08016 | [4] | BOLT,M8x16mm - Course Thread | KOBSems |
| 4. | ZM61C06020 | [1] | BOLT | KOBSems |
| 5. | ZM73C08025 | [2] | BOLT,M8x25mm - Course Thread | KOBSems |
| 6. | YT03E01016P2 | [1] | COVER | KOB |
| 7. | YN13E01375P1 | [1] | CLIP,M8 x 8.20mm Shank | KOB |
| 8. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| 9. | 2427P1836D35 | [1] | WEATHERSEAL STRIP | KOB |
| 10. | 2427P1836D39 | [1] | WEATHERSEAL STRIP | KOB |
| 11. | 2427P1836D20 | [1] | WEATHERSTRIP | KOB |
| 12. | 2427P1836D45 | [1] | WEATHERSTRIP | KOB |
| 13. | 2427P1836D47 | [1] | WEATHERSTRIP | KOB |
| 14. | PE21C01135DJ | [2] | TRIM | KOB |
