凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (55.640.11) - HARNESS, ISO ASU ADAPTER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
305 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 0. |
87657174
|
[1] |
HARNESS
|
SAS
ISO ASU adapter
|
| 1. |
87694154
|
[1] |
CONTACT HOUSING,Male, 4 Pole
|
NH
Deutsch DT4
|
| 2. |
86622300
|
[1] |
ELEC CONNECTOR
|
ZED
4-cav Plug DT Series Superseded by part number: 87694153
|
| 3. |
87675194
|
[1] |
MULTIPOLE CONNECTOR,Female, 3 Pole
|
SAS
plastic 3c plug
|
| 4. |
225224C1
|
[1] |
ELEC CONNECTOR,Female, 5 Pin
|
IH
plastic 5c plug Superseded by part number: 87706919
|
