纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-080[05]) - AIR CONDITIONING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
647 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20M00107S001 | [19] | SCREW | KOBTapping |
| 2. | YT20M00022S002 | [1] | WIRE HARNESS | KOB |
| 3. | YN20M00107S003 | [2] | ACTUATOR | KOBMotor, Elec. Superseded by part number: YT20M00022S113 |
| 4. | YN20M00107S004 | [1] | RESISTOR | KOB Superseded by part number: LQ20M00059S039 |
| 5. | YN20M00107S006 | [1] | DAMPER | KOB |
| 6. | YN20M00107S007 | [1] | LEVER | KOB |
| 7. | YN20M00107S009 | [1] | DAMPER | KOB |
| 8. | YN20M00107S010 | [1] | LEVER | KOB |
| 9. | YN20M00107S012 | [1] | LEVER | KOB |
| 10. | YN20M00107S013 | [1] | DAMPER | KOB |
| 11. | YN20M00107S014 | [1] | LEVER | KOB |
| 12. | YN20M00107S015 | [1] | LEVER | KOB |
| 13. | YN20M00107S016 | [1] | ROD | KOB |
| 14. | YN20M00107S017 | [1] | ROD | KOB |
| 15. | YN20M00107S018 | [1] | ROD | KOB |
| 16. | YN20M00107S019 | [2] | RELAY | SM |
| 17. | YN20M00107S020 | [1] | EVAPORATOR | KOB |
| 18. | YN20M00107S021 | [1] | VALVE | KOBAssy. |
| 19. | 2445Z1604D4 | [1] | O-RING | KOB |
| 20. | 2445Z1604D5 | [2] | O-RING | KOB |
| 21. | YN20M00107S024 | [2] | SCREW | SMCap |
| 22. | YN20M00107S026 | [1] | HOLDER | KOB |
| 23. | YN20M00107S027 | [1] | CORE | KOB |
| 24. | YN20M00107S028 | [1] | HOLDER | KOB |
| 25. | YN20M00107S031 | [6] | SCREW | KOBTapping |
| 26. | YN20M00107S051 | [1] | PLATE | SM |
| 27. | YN20M00107S054 | [1] | SCREW | SMCap |
| 28. | YN20M00107S060 | [1] | PACKING | KOB |
| 29. | YN20M00107S061 | [1] | PACKING | KOB |
| 30. | YN20M00107S062 | [1] | PACKING | KOB |
| 31. | YN20M00107S063 | [1] | O-RING | SM Superseded by part number: 2445Z1604D6 |
| 32. | YN20M00107S077 | [1] | GASKET | SMPacking |
| 33. | YN20M00107S078 | [1] | RIGID TUBE | SM |
| 34. | YN20M00107S079 | [1] | RIGID TUBE | SM |
| 35. | YN20M00107S082 | [1] | RIGID TUBE | SM |
| 36. | YN20M00107S083 | [1] | BRACKET | SM |
| 37. | YN20M00107S084 | [1] | BOX | SMCase |
| 38. | YN20M00107S085 | [1] | SENSOR | SMThermometer |
| 39. | YN20M00107S093 | [1] | BOX | SMCase |
| 40. | YN20M00107S094 | [1] | THERMOSTAT | SM |
| 41. | YN20M00117F3 | [1] | AIR CONDITIONER | KOB Superseded by part number: YN20M00117F4 |
| 42. | YN20M00107S111 | [1] | ELECTRIC BLOWER | KOBAssy. |
