纽荷兰零件查询(E80BMSR) - COMPACT CRAWLER EXCAVATOR ASN LF06-04501 (NBTA18037) (01-080[06]) - AIR CONDITIONING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
776 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN20M00107S087 | [1] | BOX | SMCase |
| 2. | YN20M00107S036 | [1] | GUARD | SMDumper |
| 3. | YN20M00107S037 | [1] | GUARD | SMDumper |
| 4. | YN20M00107S038 | [1] | GUARD | SMDumper |
| 5. | YN20M00107S045 | [1] | LEVER | SM |
| 6. | YN20M00107S050 | [1] | ROD | SM |
| 7. | YN20M00107S003 | [1] | ACTUATOR | KOBMotor, Elec. Superseded by part number: YT20M00022S113 |
| 8. | YN20M00107S039 | [1] | GASKET | SMPacking |
| 9. | YN20M00107S040 | [1] | GASKET | SMPacking |
| 10. | YN20M00107S001 | [4] | SCREW | KOBTapping |
| 11. | YN20M00107S031 | [3] | SCREW | KOBTapping |
| 12. | YN20M00107S092 | [1] | PLATE | SM |
| 13. | YN20M00107S098 | [1] | MOTOR HOUSING | KOBCase |
| 14. | YN20M00107S099 | [1] | LEVER | KOB |
| 15. | YN20M00107S100 | [1] | LEVER | KOB |
| 16. | YN20M00107S101 | [1] | LEVER | KOB |
| 17. | YN20M00107S102 | [1] | LEVER | KOB |
| 18. | YN20M00107S103 | [1] | LEVER | KOB |
| 19. | YN20M00107S104 | [1] | LEVER | KOB |
| 20. | YN20M00107S105 | [1] | ROD | KOB |
| 21. | YN20M00107S106 | [1] | ROD | KOB |
| 22. | YN20M00107S107 | [3] | SELF-TAP SCREW | KOBTapping |
| 23. | YN20M00107S108 | [3] | BUSHING | KOB |
| 24. | YN20M00107S109 | [4] | ROD | KOB |
