神钢零件查询(MD200BLC) - EXCAVATOR ASN YQ0565 (1/80-12/06) (11-116) - CYLINDER ASSY (ARM) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
763 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2438U941F1 | [1] | CYLINDER | KOB Superseded by part number: 2438U1108F1 |
| 1. | 2438U941S1 | [1] | BARREL | KOB |
| 2. | 2438U941S2 | [2] | BUSHING | KOB |
| 2. | 2438U941S3 | [4] | DUST CAP | KOB |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON - ROD |
| 5. | 2438U941S5 | [1] | PISTON | KOB |
| 6. | ZD12G09000 | [1] | O-RING,89.40mm ID x 95.60mm OD x 3.10mm | KOBID 89.40 ± 0.77 x OD 95mm |
| 7. | ZD75G09000 | [2] | RING | KOB |
| 8. | 2438U982S6 | [1] | SEAL | KOB |
| 9. | 2438U921S8 | [2] | RING | KOB |
| 10. | 2438U941S10 | [2] | WEAR RING | KOB |
| 11. | 2438U941S11 | [1] | NUT | KOB |
| 12. | 2438U588S11 | [1] | LOCKING RING | KOB |
| 13. | 2438U941S13 | [1] | RING | KOB |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPLUNGER, CUSHION |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONSTOPPER |
| 16. | 2438U941S16 | [1] | AIR CONDITIONER | KOB |
| 17. | 2438U394S12 | [1] | BUSHING | KOB Superseded by part number: 2405U104D100050 |
| 18. | 2418U112D74 | [1] | CLIP | KOB |
| 19. | ZD12P13500 | [2] | O-RING | KOB |
| 20. | 2438U921S16 | [2] | RING | KOB Superseded by part number: 2438U921S33 |
| 21. | 2438U921S14 | [1] | O-RING | KOB |
| 22. | R45P0050D11 | [1] | SEAL | KOB |
| 23. | 45Z91D117 | [1] | O-RING | KOB |
| 24. | 24838U17-18 | [1] | KIT | KOBPACKING Superseded by part number: 2438U1965S11 |
| 25. | 2438U588S38 | [1] | DUST CAP | KOB |
| 26. | ZS23C16065 | [16] | SCREW,Hex Socket Head, M16 x 65mm | KOBM16x2.0x65mm |
| 27. | 2438U921S29 | [1] | CHECK VALVE | KOB |
| 28. | 2438U921S32 | [1] | SPRING | KOB |
| 29. | 2438U921S28 | [1] | SPACER | KOB |
| 30. | ZE82T06000 | [1] | PLUG | KOBPipe, 3/8" PT |
| 31. | 2438U941S31 | [1] | BRACKET | KOB |
| 32. | 2438U921S25 | [1] | BUCKET | KOB |
| 33. | ZS16C10030 | [2] | CAPSCREW | KOBSCREW M10x1.50x30mm Superseded by part number: ZS18C10030 |
| 34. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 35. | ZE82T02000 | [1] | PLUG | KOBPipe, 1.25" PT |
| . . | 2438U941R100 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF 19 - 25 Superseded by part number: 2438U941R100P |
| . . | 2438U941R200 | [1] | REPAIR KIT | KOBREPAIR KIT, CONSISTS OF REF 6 - 10 |
| . . | 2438U941R300 | [1] | CYLINDER | KOBREPAIR KIT, CONSISTS OF REF 4, 14 & 15 |
