凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.150.02) - TANKS, SUPPORTS, KEY COVER (2 TANK) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
549 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9706729
|
[4] |
BOLT,Hex, 7/16" - 14 x 1", Gr 5, Full Thd
|
NH
|
| 2. |
88206
|
[6] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 4. |
87689
|
[8] |
BOLT,1/2"-13 x 1.813" OAL, Gr 5
|
NH
|
| 5. |
280980
|
[28] |
NUT,7/16"-14, GC
|
NH
|
| 6. |
86992215
|
[8] |
LOCK NUT,1/2"-13, GC
|
GFD
|
| 7. |
80702
|
[50] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 8. |
80700
|
[8] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 9. |
87337
|
[4] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
NH
|
| 10. |
80680
|
[6] |
LOCK WASHER,3/8 0.381 CST ZND
|
NH
|
| 11. |
280375
|
[4] |
NUT,3/4"-10, GC
|
WIN
|
| 12. |
84972
|
[8] |
JAM NUT,Jam, 3/4"-10, G2
|
NH
|
| 13. |
9637916
|
[20] |
BOLT,Hex, 7/16" - 14 x 1 1/2", Gr 5
|
NH
|
| 14. |
6717
|
[4] |
BOLT,Hex, 3/4" - 10 x 5", Gr 5, Full Thd
|
FLX
|
| 18. |
412907A1
|
[2] |
DECAL
|
FLX
reflector red 2.9" x 4.3"
|
| 19. |
311864A1
|
[6] |
REFLECTOR
|
CAS
Retroreflective Amber 1.375" x 7.25"
|
| 22. |
51200060
|
[2] |
SEAL
|
FLX
wide tank interface
|
| 25. |
87643140
|
[1] |
DECAL
|
SAS
Precision Air 2280 LH
|
| 25. |
87643142
|
[1] |
DECAL
|
SAS
Precision Air 2330 LH
|
| 26. |
87643141
|
[1] |
DECAL
|
SAS
Precision Air 2280 RH
|
| 26. |
87643143
|
[1] |
DECAL
|
SAS
Precision Air 2330 RH
|
| 27. |
GD-500.71
|
[1] |
WARNING DECAL
|
FLX
Do Not Ride
|
| 28. |
GD-500.79
|
[1] |
WARNING DECAL
|
FLX
Stop Fan
|
| 29. |
GL-294
|
[1] |
PLATE
|
FLX
decal tank safety
|
| 30. |
GL-700.08
|
[1] |
DECAL
|
FLX
attention before filling
|
| 31. |
GL-700.15
|
[2] |
DECAL
|
FLX
tank 1
|
| 31. |
87544841
|
[1] |
DECAL
|
SAS
118 bu
|
| 31. |
87545170
|
[1] |
DECAL
|
SAS
142 bu
|
| 32. |
GL-700.16
|
[2] |
DECAL
|
FLX
tank 2
|
| 32. |
87544840
|
[1] |
DECAL
|
SAS
93 bu
|
| 32. |
87545169
|
[1] |
DECAL
|
SAS
102 bu
|
| 36. |
87613744
|
[2] |
RAIL ASSY.
|
SAS
tank support top RH
|
| 37. |
GL-131FR
|
[2] |
SUPPORT
|
FLX
tank end rail bottom
|
| 38. |
GL-140FR
|
[4] |
SUPPORT
|
FLX
tank rail
|
| 39. |
87611689
|
[2] |
TANK
|
SAS
support side bottom
|
| 40. |
GL-156FR
|
[2] |
SUPPORT
|
FLX
tank end top
|
| 41. |
GL-607FR
|
[2] |
STRAP
|
FLX
anchor tank seal
|
| 42. |
87420890
|
[1] |
TANK
|
SAS
116 bushel female Superseded by part number: 87417292
|
| 42. |
87420924
|
[1] |
TANK
|
SAS
142 bushel female Superseded by part number: 87417295
|
| 44. |
87420926
|
[1] |
TANK
|
SAS
186 bushel male Superseded by part number: 87417294
|
| 44. |
GM-623
|
[1] |
TANK
|
FLX
154 bushel male
|
| 100. |
GM-304K
|
[1] |
KIT
|
SAS
tank pull down
|
