凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.150.BK[01]) - DELUXE AUGER HOPPER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
685 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47410040
|
[1] |
HOPPER
|
SAS
Deluxe Auger Hopper Assembly Incl 2 - 29
|
| 2. |
47410045
|
[1] |
HOPPER
|
SAS
Deluxe Auger
|
| 3. |
47782500
|
[1] |
COVER
|
SAS
Incl Decal
|
| 4. |
88542
|
[4] |
BOLT,Hex, 1/4"-20 x 1/2", Gr 5
|
NH
|
| 5. |
NS
|
[1] |
NOT SERVICED
|
BAS
Auger Hopper Gear Box
|
| 6. |
84383971
|
[1] |
SHEET
|
SAS
Rubber Hopper Top
|
| 7. |
84384066
|
[1] |
AUGER FLIGHT
|
SAS
Hopper
|
| 8. |
84418242
|
[1] |
BEARING ASSY
|
SAS
Auger Bearing
|
| 9. |
88966
|
[2] |
BOLT,Hex, 1/2" - 20 x 4", Gr 8
|
GI
|
| 10. |
87333768
|
[2] |
NUT,1/2" - 20
|
GI
|
| 11. |
9549
|
[1] |
FLANGED BEARING
|
FLX
Bearing Flange 2 Hole Superseded by part number: 50591, 84330070, 47577183
|
| 12. |
280497
|
[2] |
CARRIAGE BOLT,Short Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd
|
NH
|
| 13. |
86629544
|
[2] |
NUT,5/16” – 18, GR B
|
NH
Superseded by part number: 280736
|
| 14. |
84383978
|
[1] |
GRATE
|
SAS
Auger Course
|
| 15. |
81821889
|
[1] |
BOLT,Hex, 3/8" - 16 x 7/8", Gr 5, Full Thd
|
BAS
Superseded by part number: 280643
|
| 16. |
47392035
|
[1] |
SECURING STRAP
|
SAS
Hopper End Painted
|
| 17. |
47392031
|
[2] |
SECURING STRAP
|
SAS
Hopper Side Painted
|
| 18. |
87657
|
[12] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
NH
|
| 19. |
9635082
|
[12] |
NUT,5/16" - 18, Gr 5
|
NH
|
| 20. |
88206
|
[8] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
NH
|
| 21. |
9637692
|
[9] |
NUT,3/8"-16, GB
|
NH
|
| 22. |
47392036
|
[1] |
COVER
|
SAS
Hopper Removable
|
| 23. |
87016
|
[9] |
WASHER,0.41" ID x 0.81" OD x 0.07" Thk
|
NH
|
| 24. |
47408276
|
[1] |
DOOR
|
SAS
Cleanout
|
| 25. |
47411825
|
[1] |
CLIP
|
SAS
Clip Door LH
|
| 26. |
47428381
|
[1] |
CLIP
|
SAS
Clip Door RH
|
| 27. |
47411827
|
[1] |
LATCH
|
SAS
Latch Cleanout Door
|
| 28. |
88011
|
[1] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5
|
NH
|
| 29. |
84012893
|
[1] |
DECAL
|
ZED
Warning
|
