凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.180.AU[01]) - DELUXE AUGER LINKAGE ARMS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
453 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47446459
|
[2] |
SPACER
|
SAS
Auger T Lock Black
|
| 2. |
87314823
|
[1] |
BOLT
|
SAS
.625 X 3 Grade 8 Superseded by part number: 426-1056
|
| 3. |
47377873
|
[1] |
LINKAGE
|
SAS
Lower Incl Bushings
|
| 4. |
6635
|
[10] |
BUSHING,25.5mm ID x 31.84mm OD x 25.4mm L
|
FLX
1.25 X 1 X 1L Superseded by part number: 87420246
|
| 5. |
47377900
|
[1] |
LINKAGE
|
SAS
Upper Arm Incl Bushings
|
| 6. |
87500592
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 19.05mm L
|
SAS
1.25.X1 X .75L
|
| 7. |
47377942
|
[1] |
LINK
|
SAS
Arm Inner Incl Bushing
|
| 8. |
7995
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 19.05mm L
|
FLX
1.25 X 1 X.75 Superseded by part number: 87500592
|
| 9. |
47377957
|
[1] |
LINK
|
SAS
Arm Outer Incl Bushing
|
| 10. |
22093
|
[2] |
BUSHING,1-1/2" ID x 1-3/4" OD x 1" Thk
|
FLX
1.75 X 1.5 X l LG
|
| 11. |
47369793
|
[1] |
SUPPORT
|
SAS
Auger T Black
|
| 12. |
47369298
|
[1] |
CLEVIS
|
SAS
Auger Pivot Incl Bushing
|
| 13. |
84271625
|
[1] |
BRACKET
|
SAS
Hose Guide
|
| 14. |
84384076
|
[4] |
PIN,25.4mm OD x 180mm L
|
SAS
25.4 X 163
|
| 15. |
50032
|
[4] |
BOLT,Hex, 1/2" - 13 x 2 1/4", Gr 8
|
WIN
|
| 16. |
9636698
|
[6] |
NUT,1/2"-13, GB
|
NH
Superseded by part number: 88871
|
| 17. |
86632585
|
[1] |
WASHER,1.53" ID x 2.25" OD x 0.06" Thk
|
FOR
|
| 18. |
87338
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
NH
|
| 19. |
85700693
|
[2] |
NUT,5/8" - 11, Gr C
|
NH
|
| 20. |
87339
|
[2] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
NH
|
