凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.180.AU[02]) - DELUXE AUGER INNER ARM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
192 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47374750
|
[1] |
ARM
|
SAS
Deluxe Auger Inner Incl 2 - 8
|
| 2. |
87361
|
[2] |
WASHER,0.28" ID x 0.62" OD x 0.07" Thk
|
NH
|
| 3. |
CA-250
|
[1] |
PAD
|
FLX
Stop
|
| 4. |
87716
|
[2] |
BOLT,1/4"-20 x 1-1/4", Cl 5
|
PA
|
| 5. |
86625061
|
[2] |
NUT,1/4"-20, GB
|
SAS
|
| 6. |
7995
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 19.05mm L
|
FLX
1.25 X 1 X .75L Superseded by part number: 87500592
|
| 7. |
6636
|
[4] |
BUSHING
|
CAS
1.5 X 1.25 X 1L Superseded by part number: 87420247
|
| 8. |
6635
|
[1] |
BUSHING,25.5mm ID x 31.84mm OD x 25.4mm L
|
FLX
1.25 X 1 X 1L Superseded by part number: 87420246
|
