凯斯零件查询(2330) - PRECISION AIR CART (1/08-12/15) (80.180.AU[03]) - DELUXE AUGER FRONT SADDLE SUPPORT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47403317
|
[1] |
SUPPORT
|
SAS
Bottom Front Saddle
|
| 2. |
GL-791
|
[1] |
HEADLESS PIN
|
FLX
Lower Auger Support
|
| 3. |
47404589
|
[1] |
SUPPORT
|
SAS
Top Fron Saddle
|
| 4. |
47445222
|
[1] |
LATCH
|
SAS
Adjustable Draw
|
| 5. |
87106279
|
[1] |
PIN,6.4mm OD
|
GI
Klik
|
| 6. |
86511191
|
[2] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 7. |
87325445
|
[2] |
WASHER,1.25" ID x 1.88" OD x 0.07" Thk
|
SAS
1.250 X 1
|
| 8. |
1312
|
[4] |
WASHER,1 9/32" x 2" x .120"
|
FLX
Superseded by part number: 86632583
|
| 9. |
87343
|
[2] |
LOCK PIN,6.35mm OD x 44.45mm L, Slotted
|
GI
|
| 10. |
88421
|
[1] |
BOLT,Hex, 3/4" - 10 x 5", Gr 5
|
WIN
|
| 11. |
280375
|
[1] |
NUT,3/4"-10, GC
|
WIN
|
| 12. |
442-11012
|
[3] |
SCREW,Cross Oval Hd, #10-24 x 3/4"
|
CAS
Superseded by part number: 87023135
|
| 13. |
86632551
|
[3] |
NUT,#10-24, GB
|
PA
|
| 14. |
8670
|
[8] |
RIVET,Pop, 3/16" OD x 3/4" L
|
FLX
.188 X .75
|
| 15. |
47404590
|
[1] |
PAD
|
SAS
Lower
|
| 16. |
47406571
|
[1] |
PAD
|
SAS
Upper
|
