凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (35.100.XX[03]) - AUGER HYDRUALICS 460/555/580 BUSHEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
845 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87458127
|
[1] |
SLEEVE
|
SAS
Hydraulic Hose Protector
|
| 2. |
87458128
|
[4] |
PROTECTIVE SLEEVE,64.5mm ID x 1117.6mm L
|
SAS
Hydraulic Hose Protector
|
| 3. |
86625263
|
[4] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 4. |
47739968
|
[2] |
HYDRAULIC HOSE
|
SAS
19 X 6490 mm
|
| 5. |
47739975
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 6960 mm
|
| 6. |
47739977
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 7560 mm
|
| 7. |
47739978
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 5510 mm
|
| 8. |
47739979
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 1290 mm
|
| 9. |
47739980
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 1550 mm
|
| 10. |
47739981
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 3420 mm
|
| 11. |
47739983
|
[1] |
HYDRAULIC HOSE
|
SAS
10 X 3830 mm
|
| 12. |
47499741
|
[1] |
HYDRAULIC HOSE
|
SAS
19 X 3430 mm
|
| 13. |
47499744
|
[1] |
HYDRAULIC HOSE
|
SAS
19 X 3350 mm
|
| 14. |
84490493
|
[2] |
HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 203.2mm Stroke
|
SAS
|
| 15. |
84490498
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 28.57mm Rod, 406.4mm Stroke
|
SAS
|
| 16. |
47368417
|
[1] |
HYDRAULIC CYLINDER
|
SAS
38 X 162 mm Superseded by part number: 47682454
|
| 17. |
84289687
|
[1] |
90 ELBOW
|
WIC
37FL
|
