凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (35.100.XX[02]) - AUGER HYDRUALICS 460/555/580 BUSHEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
442 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84271625
|
[1] |
BRACKET
|
SAS
Hose Guide
|
| 2. |
84583373
|
[1] |
SUPPORT
|
SAS
Hose Guide Swivel
|
| 3. |
87020818
|
[1] |
LOCK PIN,1/4" OD x 2" OAL, Slotted
|
EML
|
| 4. |
86983984
|
[3] |
CLAMP
|
SAS
Hose
|
| 5. |
88044
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
NH
|
| 6. |
88902
|
[6] |
NUT,3/8"-16
|
NH
|
| 7. |
CC-106
|
[8] |
HOSE CLAMP
|
FLX
Hose
|
| 8. |
80012047
|
[1] |
BOLT,Hex, 3/8" - 16 x 4", Grade 5
|
WIN
|
| 9. |
88444
|
[3] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
NH
|
| 10. |
86512936
|
[1] |
ELBOW,9/16" - 18 JIC x 7/16" - 20 ORB
|
WIN
|
| 11. |
9672438
|
[1] |
PLUG,7/16" - 20 ORB
|
WIN
|
| 12. |
87329788
|
[5] |
90 ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring
|
SAS
|
| 13. |
87325444
|
[2] |
WASHER,1.02" ID x 1.5" OD x 0.07" Thk
|
SAS
|
| 14. |
84361344
|
[6] |
PIN
|
SAS
25.4 X 73.15
|
| 15. |
87019495
|
[12] |
SNAP RING,#98, Ext
|
GFD
|
| 16. |
9479
|
[1] |
PLUG
|
SAS
Breather
|
| 17. |
87699214
|
[1] |
CLEVIS PIN
|
BRR
.325 X 3.156"
|
| 18. |
80755
|
[2] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 19. |
84224888
|
[1] |
CLEVIS PIN
|
BRR
.625 X 2.696"
|
| 20. |
47734997
|
[1] |
SUPPORT
|
SAS
Valve Block Mount
|
| 21. |
84556425
|
[1] |
VALVE
|
SAS
Deluxe Auger Control
|
| 22. |
330344
|
[2] |
45 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
WIN
|
| 23. |
84555687
|
[6] |
HYD CONNECTOR
|
SAS
37FL X 6-8
|
| 24. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 25. |
367841A1
|
[1] |
ELBOW
|
CAS
Orifice
|
| 26. |
83918746
|
[2] |
WASHER,0.34" ID x 0.69" OD x 0.07" Thk
|
FOR
Superseded by part number: 44722S36
|
| 27. |
412110
|
[2] |
BOLT,Hex, M8 x 1.25 x 170mm, Cl 8.8
|
NH
Superseded by part number: 8900129024
|
| 28. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 29. |
47697609
|
[1] |
WIRE HARNESS
|
SAS
Air Cart Superseded by part number: 47960646
|
| 30. |
47705045
|
[2] |
BRACKET
|
SAS
Reciever Mount
|
| 31. |
84536987
|
[1] |
PACKAGE
|
SAS
Reciever
|
| 32. |
47818624
|
[2] |
U-BOLT
|
SAS
M8
|
| 33. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 34. |
8258
|
[8] |
SELF-TAP SCREW,Phillips Drive, Pan Head, #8 - 32 x 3/8"
|
FLX
|
