纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-52A) - OIL AND VACUUM PIPING, ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
188 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8970454000 | [1] | PIPE | KOBOil, Pump To C/bl |
| . . | VI9095714100 | [2] | SEAL | KOBOil Pipe |
| . . | VI8980903140 | [4] | PIPE | KOBOil, Oil Jet |
| . . | VI8980959780 | [1] | PIPE | KOBOil, Turbocharger Feed |
| . . | VI8980961320 | [1] | BOLT | KOBEye, Oil Pipe, Turbocharger Side |
| A. | VI8943626721 | [2] | GASKET | KOBOil Pipe, Turbocharger |
| . . | VI8980305640 | [1] | RETURN PIPE | KOBAsm Oil, Turbocharger |
| . . | VI9099061731 | [1] | EYEBOLT | KOBBolt Eye, Oil Pipe Fix Superseded by part number: VI1096750780 |
| . . | VI9091605060 | [2] | WASHER | KOBPl |
| . . | VI8971757030 | [1] | CHECK VALVE | KOBAsm |
| . . | VI9095714160 | [1] | SEAL | KOBCheck Vlv |
