纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-57A) - EMISSION PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
965 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8980305971 | [1] | VALVE | KOBEgr |
| . . | VI8980305360 | [1] | GASKET | KOBEgr Vlv |
| . . | VI0911801080 | [4] | NUT | KOBEgr Vlv |
| . . | VI5093000681 | [4] | STUD | KOBEgr Vlv |
| A. | VI8973679180 | [2] | GASKET | KOBEgr Pipe |
| B. | VI8976018360 | [1] | GASKET | KOBEgr Pipe |
| C. | VI8980305330 | [2] | GASKET | KOBEgr Pipe |
| . . | VI8980116961 | [1] | BOLT | KOBPipe |
| . . | VI8973296310 | [1] | CABLE CLIP | KOBHarness |
| A. | VI0280506100 | [1] | BOLT | KOBBrkt |
| B. | VI0280508200 | [2] | BOLT | KOBBrkt |
| C. | VI0280508350 | [1] | BOLT | KOBBrkt |
| D. | VI0280508400 | [1] | BOLT | KOBBrkt |
| . . | VI8971616070 | [2] | NUT | KOBEgr Pipe |
| A. | VI8973780760 | [3] | BOLT | KOBEgr Cooler |
| B. | VI8980654810 | [3] | BOLT | KOBEgr Cooler |
| . . | VI8980305260 | [1] | BRACKET | KOBEgr Cooler |
| . . | VI8980958070 | [1] | COOLER | KOBEgr Superseded by part number: VI8980958071 |
| . . | VI8980958080 | [1] | PIPE | KOBEgr |
| . . | VI8980305310 | [1] | PIPE | KOBEgr |
| . . | VI8980960780 | [1] | ADJUSTING PLATE | KOBPipe, Egr Superseded by part number: VI8980960781 |
| . . | VI8980727120 | [1] | PLUG | KOBEgr Cooler |
| . . | VI9095714100 | [1] | SEAL | KOBPlug |
