纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (B118M-89A[1]) - TIMING CHAIN CASE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | VI8980900300 | [1] | WEIGHT | KOBFly |
| . . | VI8971474893 | [1] | SLEEVE | KOBFlyweight |
| A. | VI9081508500 | [1] | PIN | KOBShaft Lever |
| B. | VI9081505450 | [1] | PIN | KOBShaft Lever |
| C. | VI8970164460 | [1] | SHAFT | KOBLever |
| . . | VI8971617641 | [1] | COVER | KOBGov Shaft |
| . . | VI1097470020 | [1] | PIN | KOBLever To Link Plate |
| . . | VI8971485500 | [1] | PLATE | KOBLink, Lever To Pump |
| . . | VI5095031321 | [2] | GASKET | KOBScrew |
| A. | VI0911115060 | [3] | NUT | KOBScrew |
| B. | VI0911105060 | [1] | NUT | KOBScrew |
| . . | VI5094000480 | [1] | NUT | KOBCap, Screw |
| . . | VI5156690021 | [1] | CAP | KOBIdle Set |
| . . | VI8980928180 | [1] | CONTROL LEVER | KOBCont |
| . . | VI8970346424 | [1] | LEVER | KOBMain Spr |
| . . | VI1096230550 | [2] | GASKET | KOBShaft, Cont |
| . . | VI8973070610 | [1] | SPRING | KOBReturn, Cont |
| . . | VI5095031350 | [2] | THRUST WASHER | KOBThrust, Lever |
| . . | VI0911105080 | [1] | NUT | KOBLever To Shaft |
| . . | VI5157292392 | [1] | EYE | KOBStart Spr |
| . . | VI8970698901 | [1] | SPRING | KOBMain, Lever Superseded by part number: VI8970769030 |
| . . | VI8980489710 | [1] | SPRING | KOBStart |
| . . | VI8971375642 | [1] | SPRING | KOBIdle |
| . . | VI8973034540 | [1] | LEVER | KOBFuel Cut |
| . . | VI8970646881 | [1] | PACKING | KOBGasket Cover |
| . . | VI8972628830 | [1] | BUSHING | KOBGear Case To Cont Lever |
| A. | VI0280506200 | [3] | BOLT | KOBCover |
| B. | VI8971322912 | [2] | BOLT | KOBCover |
| C. | VI8971322922 | [1] | BOLT | KOBCover |
| . . | VI1096050190 | [1] | PLUG | KOBCover, Gov |
| . . | VI8973035772 | [1] | LEVER GUIDE | KOB |
| . . | VI8973580000 | [1] | COVER | KOBAdj |
| . . | VI8973035830 | [1] | GUIDE | KOBPiece |
| . . | VI8970346376 | [1] | LEVER | KOBTension, Gov |
| . . | VI8970346383 | [1] | SHIFTER FORK | KOBGov |
| . . | VI8973036670 | [1] | SHAFT | KOBShifter |
| . . | VI0918055040 | [1] | SNAP RING | KOBShaft |
| . . | VI8973035802 | [1] | LEVER | KOBFloating |
| . . | VI8973695521 | [1] | PLUG | KOBShaft, Floating Lever Superseded by part number: VI5096050192 |
| . . | VI8971488650 | [1] | LINK | KOBCont, Inj Pump |
| . . | VI8970395842 | [1] | SCREW | KOBSet, Full Load |
| . . | VI8970164410 | [1] | SCREW | KOBSet, Idle Spr |
| A. | VI9091605040 | [1] | WASHER | KOBIdle Spr |
| B. | VI9091607040 | [1] | WASHER | KOBIdle Spr |
| . . | VI0918055030 | [1] | SNAP RING | KOBSet Screw |
| . . | VI5091200151 | [1] | SCREW | KOBCont Set Speed L=28 |
| . . | VI8943176381 | [1] | SCREW | KOBCont Set Speed L=38 |
| . . | VI0915108080 | [2] | WASHER | KOBLk |
