凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (35.911.AB[01]) - HYDRAULIC LIFT CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
751 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87505171
|
[1] |
HYDRAULIC CYLINDER,31.75mm Rod, 406.4mm Stroke
|
SAS
Outer Boom Fold, 2 - 1/2" x 16", 1 - 1/4" Rod, Incl 2 - 15 Superseded by part number: 47582359
|
| 2. |
87314803
|
[1] |
SET SCREW,Hex Skt, 3/8" - 16 x 1/2"
|
SAS
|
| 3. |
6944
|
[1] |
PLUG,Hex Soc, 3/4"-16 ORB
|
FLX
|
| 4. |
3326
|
[1] |
PIN
|
FLX
1" x 2 - 7/8", Incl 14 Superseded by part number: 84361344, 87019495
|
| 5. |
87577842
|
[1] |
SHAFT
|
SAS
1 - 1/4" x 16" Stroke
|
| 6. |
7997
|
[1] |
CLEVIS
|
FLX
1 - 1/8" - 12 Thread, 1" Pin Superseded by part number: 87449358
|
| 7. |
87409409
|
[1] |
HEAD
|
SAS
Cylinder Front
|
| 8. |
439277A1
|
[1] |
PISTON
|
SAS
2 - 1/2" Dia
|
| 9. |
425038A1
|
[1] |
NUT
|
FLX
3/4" - 16, GA
|
| 10. |
87577843
|
[1] |
TUBE,2.6 mm DIA x 16 mm L
|
SAS
|
| 11. |
87577844
|
[4] |
THREADED TIE-ROD
|
SAS
Hydraulic Cylinder
|
| 12. |
9628503
|
[8] |
NUT,3/8"-16, G5
|
NH
|
| 13. |
87409437
|
[1] |
HEAD
|
SAS
Cylinder Base Superseded by part number: 439275A1
|
| 14. |
87019495
|
[2] |
SNAP RING,#98, Ext
|
GFD
Incl in 4
|
| 15. |
87577841
|
[1] |
SEAL KIT
|
SAS
2 - 1/2" Cylinder, Used on Ref 1
|
