凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (37.162.AA[01]) - FRONT HITCH TOW BEHIND 2355/3445/4465 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
881 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47522868
|
[1] |
FRAME
|
SAS
Front Hitch Case Tow Behind
|
| 1. |
47522869
|
[1] |
HITCH
|
SAS
Front Hitch New Holland Tow Behind
|
| 1. |
47522870
|
[1] |
HITCH
|
SAS
Front Hitch Flexi Coil Tow Behind
|
| 2. |
440588
|
[28] |
BOLT,Hex, M20 x 70, 8.8
|
NH
Superseded by part number: 80440588, 15224121
|
| 3. |
725637
|
[28] |
NUT,M20 x 2.5, Cl 8
|
BER
Superseded by part number: 380424
|
| 4. |
87506220
|
[1] |
HITCH
|
SAS
Base Cat IV Black
|
| 5. |
87020629
|
[2] |
BOLT,Hex, 1" - 8 x 8 1/2", Gr 8
|
SAS
|
| 6. |
87367
|
[4] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
PA
|
| 7. |
9626600
|
[2] |
NUT,1"-8, GC
|
NH
|
| 8. |
47633321
|
[1] |
CRADLE
|
SAS
Air Pack Black
|
| 9. |
47633324
|
[1] |
SUPPORT
|
SAS
Cradle Brace
|
| 10. |
47632694
|
[1] |
PIVOT
|
SAS
Air Pack Cradle
|
| 11. |
47632658
|
[1] |
SUPPORT
|
SAS
Tow Behind Air Pack
|
| 12. |
352892A1
|
[2] |
U-BOLT
|
CAS
|
| 13. |
86619801
|
[4] |
FLANGE NUT,M8 x 1.25, Cl 8
|
PA
Superseded by part number: 87681210
|
| 14. |
14610571
|
[2] |
COTTER PIN
|
COE
Spring
|
| 15. |
87023158
|
[1] |
WASHER,1.31" ID x 2.5" OD x 0.15" Thk
|
SAS
|
| 16. |
43129
|
[4] |
BOLT,Hex, M8 x 1.25 x 40mm, LH Thd, Cl 8.8
|
NH
Superseded by part number: 16044024
|
| 17. |
68841
|
[4] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
| 18. |
86625263
|
[4] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 19. |
8060
|
[2] |
CAP
|
FLX
1.5 X .750 Long Black
|
