纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC370[2]) - MOTOR ASSY (PROPELLING) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
745 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT15V00012F1 | [1] | MOTOR | KOBMotor Assy (propelling) |
| 1. | YT15V00012S001 | [1] | CASE | KOBCasing |
| 2. | YT15V00012S002 | [1] | SEAL | KOBFloating |
| 3. | YT15V00012S003 | [2] | BALL BEARING | KOB |
| 4. | YT15V00012S004 | [1] | RING NUT | KOB |
| 5. | YT15V00012S005 | [1] | CASE | KOBGear |
| 6. | YT15V00012S006 | [1] | SUN GEAR | KOB |
| 7. | YT15V00012S007 | [3] | PLANETARY GEAR | KOB |
| 8. | YT15V00012S008 | [3] | NEEDLE BEARING | KOB |
| 9. | YT15V00012S009 | [1] | CARRIER | KOB |
| 10. | YT15V00012S010 | [1] | SUN GEAR | KOB |
| 11. | YT15V00012S011 | [4] | PLANETARY GEAR | KOB |
| 12. | YT15V00012S012 | [4] | BUSHING | KOB |
| 13. | YT15V00012S013 | [4] | NEEDLE BEARING | KOB |
| 15. | YT15V00012S015 | [1] | THRUST PLATE | KOB |
| 16. | YT15V00012S016 | [1] | THRUST PLATE | KOB |
| 17. | YT15V00012S017 | [4] | THRUST PLATE | KOB |
| 18. | YT15V00012S018 | [8] | SCREW | KOB |
| 19. | YT15V00012S019 | [1] | WASHER | KOB |
| 20. | YT15V00012S020 | [1] | PIN | KOB |
| 21. | YT15V00012S021 | [1] | COVER | KOBCover |
| 22. | YT15V00012S022 | [12] | LOCK WASHER | KOBSpring, Washer |
| 23. | YT15V00012S023 | [12] | BOLT | KOBBolt |
| 24. | YT15V00012S024 | [3] | PLUG | KOB |
| 25. | ZD11P01400 | [3] | O-RING | KOB |
| 26. | YT15V00012S026 | [1] | SHAFT | KOB |
| 27. | YT15V00012S027 | [1] | BLOCK | KOBBarrel, Cylinder |
| 28. | YT15V00012S028 | [1] | BALL | KOB |
| 29. | YT15V00012S029 | [1] | RETAINER | KOB |
| 30. | YT15V00012S030 | [1] | CAM | KB |
| 31. | NSS | [9] | NOT SERVICED SEPARATELY | CONPiston |
| 33. | YT15V00012S033 | [1] | PLATE | KOBValve |
| 34. | YT15V00012S034 | [1] | PLATE | KOBPlate |
| 37. | YT15V00012S037 | [1] | BALL BEARING | KOB |
| 38. | YT15V00012S038 | [1] | BALL BEARING | KOB |
| 39. | YT15V00012S039 | [1] | OIL SEAL | KOB |
| 40. | YT15V00012S040 | [1] | SPRING | KOB |
| 41. | YT15V00012S041 | [1] | SPRING | KOB |
| 42. | YT15V00012S042 | [2] | BALL | KOBSteel |
| 43. | YT15V00012S043 | [3] | PIN | KOB |
| 44. | YT15V00012S044 | [1] | SNAP RING | KOB |
| 45. | YT15V00012S045 | [1] | PIN | KOBSpring |
| 46. | YT15V00012S046 | [1] | PISTON | KOBBrake |
| 47. | YT15V00012S047 | [2] | PLATE | KOBFriction |
| 48. | YT15V00012S048 | [2] | STEEL PLATE | KOB |
| 49. | YT15V00012S049 | [10] | SPRING | KOBSpring |
| 50. | YT15V00012S050 | [1] | PLATE | KOBPlate |
| 51. | YT15V00012S051 | [2] | PLUG | KOB |
| 52. | YT15V00012S052 | [2] | POPPET | KOB |
| 53. | YT15V00012S053 | [2] | SPRING | KOB |
| 54. | ZD12P01800 | [2] | O-RING | KOB |
| 55. | YT15V00012S055 | [1] | O-RING | KOB |
| 56. | YT15V00012S056 | [1] | RING | KOBBack Up |
| 57. | ZD12G13000 | [1] | O-RING,129.40mm ID x 135.60mm OD x 3.10mm | KOB |
| 58. | YT15V00012S058 | [1] | RING | KOBBack Up |
| 59. | YT15V00012S059 | [1] | O-RING | KOB |
| 60. | YT15V00012S060 | [2] | PIN | KOBPin |
| 61. | YT15V00012S061 | [3] | BOLT | KOBBolt |
| 62. | YT15V00012S062 | [1] | COVER | KOBMotor Cover |
| 63. | YT15V00012S063 | [1] | SPOOL | KOB |
| 65. | YT15V00012S065 | [2] | SPRING SEAT | KOBPusher |
| 66. | YT15V00012S066 | [2] | SPRING | KOB |
| 67. | YT15V00012S067 | [2] | COVER | KOBCover |
| 68. | ZD12P02800 | [2] | O-RING | KOB |
| 69. | YT15V00012S069 | [1] | ORIFICE | KOBOrifice |
| 70. | YT15V00012S070 | [1] | SPOOL | KOB |
| 71. | YT15V00012S071 | [1] | ORIFICE | KOB |
| 72. | YT15V00012S072 | [2] | BALL | KOBSteel |
| 73. | YT15V00012S073 | [2] | PLUG | KOB |
| 74. | ZD12P00800 | [4] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOB |
| 87. | YT15V00012S087 | [2] | PLUG | KOB |
| 88. | ZD12P01100 | [2] | O-RING | KOB |
| 89. | YT15V00012S089 | [7] | PLUG | KOB |
| 90. | YT15V00012S090 | [3] | PLUG | KOB |
| 93. | YT15V00012S093 | [1] | SPRING | KOB |
| 94. | YT15V00012S094 | [1] | PLUG | KOB |
| 95. | YT15V00012S095 | [1] | O-RING | KOB |
| K. | YT15V00012R200 | [9] | REPAIR KIT | KOBConsists Of Item 31x1, 32x1 |
| K. | YT15V00012R300 | [1] | REPAIR KIT | KOBConsists Of Item 35x1, 36x1 |
| K. | YT15V00012R500 | [2] | REPAIR KIT | KOBConsists Of Item 75x1, 76x1, 77x1 |
