神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-015) - VALVE ASSY, BRAKE - 2436U1384F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
609 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436U1384F1 | [1] | BRAKE VALVE | KOBASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONSPOOL |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONSEAT, SPRING |
| 4. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING |
| 5. | ZD12G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 6. | ZD12P00900 | [4] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 7. | NSS | [2] | NOT SOLD SEPARAT | CONCOVER |
| 8. | NSS | [2] | NOT SOLD SEPARAT | CONVALVE |
| 9. | NSS | [2] | NOT SOLD SEPARAT | CONSPRING |
| 10. | 2436U1139S10 | [2] | PLUG | KOB |
| 11. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 12. | ZS23C12045 | [8] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm Superseded by part number: ZS28C12045 |
| 13. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 14. | ZS23C12070 | [6] | SCREW,Hex Socket Head, M12 x 70mm | KOBM12x1.75x70mm Superseded by part number: ZS28C12070 |
| 15. | 2436U1317S13 | [2] | PLUG | KOB |
