神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-017) - PUMP ASSY - 2437U205F1, F2 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
326 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2437U205F1 | [1] | PUMP | KOBCONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2437U205F3 |
| . . | 2437U205F2 | [1] | PUMP ASSY, CONSISTS OF THE FOLLOWING PARTS | PUMP ASSY, CONSISTS OF THE FOLLOWING PARTS |
| 1. | 2437U213F1 | [1] | PUMP | KOBASSY, SEE FIGURE 11-018 |
| 2. | 2436U1378F1 | [2] | REGULATOR ASSY, F1 ONLY, SEE FIGURE 11-014 | REGULATOR ASSY, F1 ONLY, SEE FIGURE 11-014 |
| 3. | 2436U1370F1 | [1] | VALVE ASSY, SOLENOID | VALVE ASSY, SOLENOID |
| 4. | 2436U1378F2 | [2] | REGULATOR ASSY F2 ONLY, SEE FIGURE 11-014 | REGULATOR ASSY F2 ONLY, SEE FIGURE 11-014 |
