凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (44.532.AE[01]) - 555, 580 BUSHEL FRONT AXLE SPINDLE ASSY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
244 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47487141
|
[1] |
HUB
|
SAS
Assembly, Complete, Incl 2 - 16
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hub, Incl in 1
|
| 3. |
7663
|
[1] |
ROLLER BEARING
|
FLX
Outer Superseded by part number: 86594308
|
| 4. |
7665
|
[1] |
BEARING CONE
|
FLX
Inner Superseded by part number: 371884A1
|
| 5. |
7657
|
[1] |
OIL SEAL
|
FLX
Hub Superseded by part number: 412775A1
|
| 6. |
7660
|
[1] |
GASKET
|
FLX
Rubber Superseded by part number: 1027681
|
| 7. |
87506238
|
[1] |
HUB CAP
|
SAS
Dust
|
| 8. |
7669
|
[4] |
BOLT
|
FLX
Dust Cap Superseded by part number: 1027683
|
| 9. |
47459889
|
[1] |
SPINDLE
|
SAS
Hub
|
| 10. |
7666
|
[1] |
SLOTTED NUT,1 1/4"-12, G2
|
FLX
Superseded by part number: 87355811
|
| 11. |
7664
|
[1] |
WASHER
|
FLX
Spindle, 1-1/4" ID Superseded by part number: 412778A1
|
| 12. |
9790660
|
[10] |
FLANGE NUT,Flg, 3/4"-16, G8
|
WIN
|
| 13. |
87400
|
[1] |
COTTER PIN,3/16" x 2"
|
WIN
|
| 14. |
7659
|
[1] |
BEARING CUP
|
FLX
Inner Superseded by part number: 371878A1
|
| 15. |
7658
|
[1] |
BEARING CUP
|
FLX
Outer Superseded by part number: 21884250
|
| 16. |
22792
|
[10] |
STUD
|
FLX
Wheel
|
| 17. |
16440421
|
[1] |
BOLT,Hex, M20 x 2.5 x 200mm, Cl 8.8
|
BRR
|
| 18. |
725637
|
[1] |
NUT,M20 x 2.5, Cl 8
|
BER
Superseded by part number: 380424
|
