纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (HC852[1]) - VALVE ASSY, SOLENOID New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
471 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT35V00027F1 | [1] | SOLENOID VALVE | KOBAssy |
| 101. | YT35V00027S101 | [1] | MOTOR HOUSING | KOBCasing |
| 171. | YN35V00047S171 | [6] | SCREW,Hex Socket Head, M5 x 12mm | SMCap Superseded by part number: ZS23C05012 |
| 601. | NSS | [1] | NOT SERVICED SEPARATELY | CONValve, Relief |
| 701. | YN35V00050F1 | [2] | SOLENOID VALVE,Cartridge W/Coil | KOBAssy, Solenoid (See HC853) |
| 702. | YN35V00051F1 | [1] | SOLENOID VALVE | KOBAssy, Solenoid (See HC854) |
| 901. | YT35V00027S901 | [1] | Name Plate | |
