凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (55.100.XX[02]) - AUGER CONTROL HARNESS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
914 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47697609
|
[1] |
WIRE HARNESS
|
SAS
Auger Control Harness Incl 2 - 15 Superseded by part number: 47960646
|
| 2. |
87692858
|
[1] |
ELEC CONNECTOR,Male
|
BN
Auger Control
|
| 3. |
84178654
|
[1] |
ELEC CONNECTOR
|
BN
RF Receiver
|
| 4. |
87687242
|
[1] |
ELEC CONNECTOR,4 Way
|
BAS
Transport Lock
|
| 5. |
87692855
|
[1] |
CONTACT HOUSING,Male, 2 Cavities
|
BN
Auger Lower
|
| 14. |
87688712
|
[1] |
WIRE CONNECTOR,Female
|
BN
10 Amp Fuse
|
| 15. |
87688863
|
[1] |
CAP
|
BN
Dust
|
