神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-024) - MOTOR ASSY (PROPELLING) - 2441U783F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
937 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U783F3 | [1] | ENGINE | KOBASSY, (PROPELLING) CONSISTS OF THE FOLLOWING PARTS Superseded by part number: 2441U783F4 |
| 1. | 2441U783S1 | [1] | CASING | |
| 2. | 2441U783S2 | [1] | COVER (REAR) | COVER (REAR) |
| 3. | 2441U783S3 | [1] | CYLINDER BLOCK | KOB |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER |
| 5. | 2441U783S5 | [3] | CLUTCH PLATE | KOB Superseded by part number: YN15V01005F2 |
| 6. | 2441U783S6 | [1] | PISTON | KOB |
| 7. | 2441U783S7 | [4] | STEP PLATE | KOBPLATE, SEPARATE |
| 8. | 2441U783S8 | [1] | PLATE | KOB |
| 9. | 2441U783S9 | [1] | SHAFT | KOB |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, SHOE |
| 11. | 2441U739S42 | [2] | BOLT | KOB |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONBUSHING |
| 13. | 2441U783S13 | [1] | SEAT BACK | KOB |
| 14. | 2441U783S14 | [1] | STOP | KOB |
| 15. | 2441U783S15 | [2] | SPACER | KOB |
| 16. | 2441U783S16 | [1] | BATTERY BOX | KOBSEAL |
| 17. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON ASSY |
| 18. | 2441U783S18 | [1] | PISTON RING | KOB |
| 19. | 2441U783S19 | [1] | PISTON RING | KOB |
| 20. | 2441U783S20 | [3] | CHECK VALVE | KOBRESTRICTOR |
| 21. | 2441U783S21 | [1] | SNAP RING | KOB Superseded by part number: ZR16X05500 |
| 22. | 2441U783S22 | [1] | LOCKING RING | KOB Superseded by part number: ZR26X11000 |
| 23. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 24. | NSS | [1] | NOT SOLD SEPARAT | CONBALL, HALF |
| 25. | NSS | [2] | NOT SOLD SEPARAT | CONPIVOT |
| 26. | 2441U783S26 | [1] | PISTON RING | KOB |
| 27. | 2441U783S27 | [1] | ORIFICE | |
| 28. | 2483U171S34 | [2] | PLUG | KOB |
| 29. | 2441U923S7 | [1] | OIL SEAL | KOB |
| 30. | 2441U783S30 | [3] | SPRING | KOB |
| 31. | 2441U783S31 | [9] | SPRING | KOB |
| 32. | 2441U783S32 | [16] | SPRING | KOB |
| 33. | 2441U923S4 | [1] | BEARING | BEARING |
| 34. | 2441U783S34 | [1] | NEEDLE BEARING | KOBBEARING |
| 35. | ZS23C18055 | [8] | SCREW,Hex Socket Head, M18 x 55mm | KOBM18x2.50x55mm |
| 36. | 2441U739S29 | [2] | PIN | KOB |
| 37. | ZD12P00700 | [1] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 38. | ZD12P00900 | [7] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 39. | ZD12P01000 | [2] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 40. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 41. | ZD12G10500 | [1] | O-RING,104.40mm ID x 110.60mm OD x 3.10mm | KOBID 14.80 ± 0.20 x OD 19mm |
| 42. | ZD12G20000 | [1] | O-RING,199.30mm ID x 210.70mm OD x 5.70mm | KOBID 199.30 ± 1.55 x OD 210mm |
| 43. | 2436R866F1 | [2] | PILOT VALVE | KOBRELIEF, SEE FIGURE 11-007 |
| 44. | 2436U1433F1 | [1] | VALVE ASSY PILOT, SEE FIGURE 11-016 | VALVE ASSY PILOT, SEE FIGURE 11-016 |
| 45. | NSS | [1] | NOT SOLD SEPARAT | CONNAME-PLATE |
| . . | 2441U783R100 | [95] | REPAIR KIT | KOB Superseded by part number: 2441U820R100 |
| . . | YN15V01005F2 | [1] | REPAIR KIT | KOBPLATE Repair Kit (includes 2441U783S5 x 3 & 2441U783S7 x 4) |
| . . | 2441U783R200 | [1] | REPAIR KIT | REPAIR KIT |
| . . | 2441U783R300 | [1] | REPAIR KIT | KOB |
