神钢零件查询(MD200BLC) - EXCAVATOR ASN YQU0001 (1/80-12/06) (11-025) - MOTOR ASSY (SWING) - 2441U785F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
541 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2441U785F1 | [1] | HYDRAULIC MOTOR | KOBASSY, (SWING) CONSISTS OF THE FOLLOWING PARTS |
| 011. | 2441U785S11 | [9] | PISTON | KOB |
| 020. | 2441U785S20 | [1] | COVER | KOBVALVE |
| 031. | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOBASSY, SEE FIGURE 11-010 |
| 101. | 2441U785S101 | [1] | SHAFT | KOB |
| 106. | 2441U785S106 | [3] | SPACER | KOB |
| 111. | 2441U785S111 | [1] | CYLINDER | KOB |
| 113. | 2441U785S113 | [1] | HUB | KOB |
| 114. | 2441U785S114 | [1] | SPRING | KOB |
| 116. | 2441U785S116 | [12] | ROD | KOB |
| 117. | 2441U785S117 | [1] | SPACER | KOB |
| 118. | 2441U785S118 | [1] | SPACER | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | 2441U785S123 | [1] | PLATE | KOB |
| 124. | 2441U785S124 | [1] | PLATE | KOB |
| 131. | 2441U785S131 | [1] | PLATE | KOB |
| 301. | 2441U785S301 | [1] | CASE | KOB |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONCOVER |
| 304. | 2441U785S304 | [1] | COVER | KOB |
| 401. | ZS23C20045 | [4] | CAP,Hex Socket Head, M20 x 45mm | KOBScrew -- M20x2.5x45mm |
| 432. | ZR16X04500 | [2] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 433. | ZR16X02500 | [1] | RING | KOBRetaining -- ID 23.2 x OD 25 x Th 1.2mm |
| 437. | ZR26X10000 | [1] | RING | KOB |
| 438. | ZR26X05800 | [1] | SEAL RETAINER | KOB |
| 443. | 2441U736S443 | [1] | BEARING | KOBROLLER |
| 444. | 2441U748S444 | [1] | BEARING | KOBBEARING, ROLLER Superseded by part number: 2441U784S444 |
| 451. | ZP26D08016 | [2] | ROLL PIN | KOB |
| 464. | 2441U722S466 | [1] | PLUG | KOB Superseded by part number: 2441U667S466 |
| 471. | ZD12G10000 | [1] | O-RING,99.40mm ID x 105.60mm OD x 3.10mm | KOBID 99.40 ± 0.85 x OD 105mm |
| 472. | 2415U188S725 | [1] | O-RING | KOB |
| 485. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 491. | 2441U556S491 | [1] | OIL SEAL | KOB Superseded by part number: R45P0031D3 |
| 702. | 2441U785S702 | [1] | PISTON | KOB Superseded by part number: LQ15V00001S015 |
| 706. | 2441U785S706 | [1] | O-RING | KOB |
| 707. | 2441U741S706 | [1] | O-RING | KOB |
| 712. | 2441U748S712 | [16] | SPRING | SPRING |
| 742. | 2441U785S742 | [2] | PLATE | KOB |
| 743. | 2441U785S743 | [3] | PLATE | KOB |
| 992. | ZE82T08000 | [2] | PLUG | KOB1/2" PT |
