纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (052-01[2]) - FULE LINES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
462 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT21P00004F1 | [1] | Fuel Lines | |
| 4. | YT21P01009P1 | [1] | BRACKET | KOBBracket |
| 5. | YT21P01012D1 | [1] | FLEXIBLE HOSE | KOB |
| 6. | PH21P01003DF | [1] | HOSE | KOB |
| 7. | PH21P01003D2 | [1] | HOSE ASSY. | KOB |
| 8. | PH21P01008D4 | [1] | FLEXIBLE HOSE | KOB |
| 9. | HX11Y04046DX | [1] | FLEXIBLE HOSE,6mm ID x 460mm L | KOB Superseded by part number: 72280610 |
| 10. | HX81X13125DX | [1] | TUBE | KOB |
| 11. | HX81X13100DX | [1] | TUBE | KOB |
| 12. | HX81X13260DX | [1] | TUBE | KOB |
| 13. | PH05P01088D5 | [8] | CLIP | KOB |
| 14. | PH05P01088D6 | [2] | CLIP | KOB |
| 15. | ZC46X19011 | [7] | CLIP | KOB |
| 16. | EW02E01015DA | [1] | CLIP | KOB |
| 17. | PY01P01043D2 | [18] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| 19. | ZS18C08070 | [1] | SCREW,Hex, M8 x 70mm | KOBCap |
| 20. | ZW16P08000 | [1] | WASHER | KOB |
| 21. | ZM73C10035 | [2] | BOLT,M10x35mm - Course Thread | KOBSems |
| 22. | ZM73C06025 | [2] | BOLT,M6x25mm - Course Thread | KOBSems |
| 23. | ZM73C10020 | [3] | BOLT,M10x20mm - Course Thread | KOBSems |
| 24. | ZM73C10016 | [6] | BOLT,M10x16mm - Course Thread | KOBSems |
| 25. | ZM73C08016 | [1] | BOLT,M8x16mm - Course Thread | KOBSems |
| 26. | PH21P01003DV | [1] | FLEXIBLE HOSE | KOB |
| 27. | HX81X13150DX | [1] | TUBE | KOB |
| 28. | YN13E01375P1 | [4] | CLIP,M8 x 8.20mm Shank | KOB |
| 29. | HX81X13120DX | [1] | TUBE | KOB |
| 1. | VI8944150773 | [1] | FILTER ASSY | KOBFuel Superseded by part number: VI8970142041 |
| 1-1. | VI8971725491 | [1] | ELEMENT | KOBFilter, Fuel Superseded by part number: YB02P00001-2 |
| 2. | VI8973112542 | [1] | FILTER ASSY | KOBSeparator, Water |
| 2-1. | VI8972133810 | [1] | ELEMENT | KOBFuel |
| 3. | VI8970415212 | [1] | FUEL PUMP | KOB |
