纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (059-01[1]) - TANK INSTAL, FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
434 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20P00035F1 | [1] | Tank Instal, Fuel | |
| . . | YT20P00042F1 | [1] | Tank Instal, Fuel | |
| A1. | ZS18C16050 | [4] | SCREW,Hex, M16 x 50mm | KOBCap |
| A2. | ZW16H16000 | [4] | WASHER | KOB |
| A3. | LE33H01017D1 | [3] | SHIM | KOB(1. 0) |
| A4. | YN52S00045F1 | [1] | SENSOR | SMAssy, Level |
| A5. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBMachine Screw |
| A6. | ZW26X05000 | [5] | LOCK WASHER | KOBLock |
| A7. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| A9. | LS21C01093D5 | [2] | TRIM | KOB |
| A10. | YN05P00010S007 | [1] | COCK, DRAIN | KOB |
| A11. | PM05P01046P1 | [1] | BOSS | KOB |
| A12. | PH21P01008D6 | [1] | FLEXIBLE HOSE | KOB |
| A13. | PH05P01088D6 | [3] | CLIP | KOB |
| A14. | PA21P01005D5 | [1] | FLEXIBLE HOSE | KOB |
| A15. | PU13E01002D1 | [1] | TUBE | KOB |
| A16. | PY01P01043D2 | [2] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| . . | YT20P00041F1 | [1] | Tank Assy, Fuel | |
| B1. | YN20P01034P2 | [1] | CAP | KOBFiller |
| B2. | YF50V00001P1 | [1] | FILTER STRAINER | KOB |
| B3. | YT20P01075P1 | [1] | FLANGE | KOB |
| B5. | ZD11G16000 | [1] | O-RING,5.7mm Thk x 159.3mm ID, 70 Duro | KOB |
| B6. | YT20P00040P3 | [1] | FUEL TANK | KOB |
