凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (55.404.AO[02]) - LIGHTING Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
206 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
134454A1
|
[2] |
LAMP,Halogen, 12V, 32W, Clear
|
CAS
Superseded by part number: 192052A1
|
| 2. |
51200040
|
[2] |
LIGHT
|
FLX
Tail/Signal Red
|
| 3. |
323866
|
[2] |
BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8
|
NH
Superseded by part number: 120091
|
| 4. |
146988
|
[4] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 5. |
385922
|
[2] |
BOLT,Hex, M16 x 2 x 45mm, Cl 8.8
|
NH
|
| 6. |
47539750
|
[1] |
MOUNT
|
SAS
Light Left Side Black
|
| 7. |
87446015
|
[1] |
BAR
|
SAS
Light Left
|
| 8. |
43140
|
[6] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 9. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
86625253
|
[6] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 11. |
47539723
|
[1] |
MOUNT
|
SAS
Light Right Side Black
|
| 12. |
87446014
|
[1] |
BAR
|
SAS
Light Right
|
