纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (100-01[1]) - HYD LINES, UPP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
899 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF03H00005F1 | [1] | PIPE | KOBHyd Lines, Upp |
| A1. | LF03H01024D2 | [1] | FLEXIBLE HOSE | KOB |
| A2. | YT02H01232D3 | [1] | FLEXIBLE HOSE | KOB |
| A3. | YT03H01025D6 | [2] | FLEXIBLE HOSE | KOB |
| A4. | YT03H01025D7 | [1] | FLEXIBLE HOSE | KOB |
| A5. | YT03H01025D8 | [1] | FLEXIBLE HOSE | KOB |
| A6. | YT03H01025D9 | [1] | FLEXIBLE HOSE | KOB |
| A7. | YT03H01025DA | [1] | FLEXIBLE HOSE | KOB |
| A9. | YT03H01026DK | [1] | FLEXIBLE HOSE | KOB |
| A10. | YT03H01026DG | [1] | FLEXIBLE HOSE | KOB |
| A11. | YT03H01026DH | [1] | FLEXIBLE HOSE | KOB |
| A12. | YT03H01003D9 | [1] | FLEXIBLE HOSE | KOB |
| A13. | YT03H01114D8 | [1] | FLEXIBLE HOSE | KOB |
| A14. | YT03H01114D9 | [1] | FLEXIBLE HOSE | KOB |
| A16. | YT03H01144D2 | [2] | FLEXIBLE HOSE | KOB |
| A17. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBCap |
| A18. | ZS18C10080 | [4] | SCREW,Hex, M10 x 80mm | KOBCap |
| A19. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBCap |
| A20. | HH25R08006G4 | [2] | HYD CONNECTOR | KOB |
| A21. | YT03H01054P1 | [2] | CONNECTION | KOB |
| A21-1. | ZD12P01800 | [1] | O-RING | KOB |
| A22. | ZA28F12006 | [2] | HYD CONNECTOR | KOB |
| A23. | ZA28F18008 | [7] | HYD CONNECTOR | KOB |
| A24. | ZA29F18008 | [4] | HYD CONNECTOR | KOB |
| A25. | ZA38F18008 | [3] | HYD CONNECTOR | SMElbow |
| A28. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| A29. | ZM73C10025 | [2] | BOLT,M10x25mm - Course Thread | KOBSems |
| A30. | YT03H01019P1 | [2] | BUSHING | KOB Superseded by part number: YN03H01075P1 |
| A31. | LF03H01026P1 | [1] | BUSHING | KOB |
| A32. | YT03H01127P1 | [2] | BUSHING | KOB |
| A33. | YW03H01183P1 | [1] | CLAMP | KOB |
| A34. | LF03H01027P1 | [1] | CLAMP | KOBClamp |
| A35. | ZY26X06030 | [1] | SPACER | KOB |
| A37. | YT03H01125P1 | [2] | PLATE | KOBPlate |
| A38. | LF03H01030P1 | [1] | PLATE | KOBPlate |
| A41. | LF03H01033P1 | [1] | BRACKET, SUPPORTING | KOBSupport |
| A42. | YT03H01135P1 | [1] | BRACKET, SUPPORTING | KOBSupport |
| A43. | LF03H01013P1 | [1] | RUBBER | KOB |
| A44. | LF03H01023D1 | [1] | RUBBER SEAL | KOB |
| A45. | LF03H01023D2 | [2] | RUBBER SEAL | KOB |
| A47. | ZW16H10000 | [5] | WASHER | KOB |
| A48. | ZW16H12000 | [1] | WASHER | KOB |
| A49. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB |
| A50. | YX03H01046P1 | [3] | CLIP | KOB |
| A53. | 2444Z3713 | [1] | HYD CONNECTOR | KOB |
| A54. | HH25R08008G6 | [1] | HYD CONNECTOR | KOB |
| A55. | ZD12P01400 | [2] | O-RING | KOB |
| . . | LF03H00010F1 | [1] | PIPE | KOBHyd Lines, Upp |
| B1. | YJ03H01036P1 | [1] | BUSHING | KOB |
