纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (090-01[1]) - HYD LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
521 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT30H00007F1 | [1] | Hyd Lines, Pump | |
| 1. | YT30H01037P1 | [1] | FLEXIBLE HOSE | KOB |
| 2. | YT30H01047P1 | [1] | PIPE | KOBTube |
| 3. | YT30H01001P1 | [1] | TUBE | KOB |
| 4. | YB03H01118P1 | [1] | HYD CONNECTOR | KOB |
| 5. | 2444Z3713 | [1] | HYD CONNECTOR | KOB |
| 8. | ZE72X04000 | [1] | PLUG | KOB |
| 9. | ZC16X06100 | [4] | CLIP | KOB |
| 10. | ZD11G05500 | [1] | O-RING,54.40mm ID x 60.60mm OD x 3.10mm | KOB |
| 11. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 12. | ZD12P02600 | [1] | O-RING | KOB |
| 13. | ZS28C10040 | [4] | CAP,Hex Socket Head, M10 x 40mm | KOBCap |
| 14. | ZS28C12035 | [4] | CAPSCREW,Hex Socket Head, M12 x 35mm | KOBSCREW Cap |
| 15. | ZW26K10000 | [4] | LOCK WASHER | KOBLock |
| 16. | ZW26K12000 | [4] | LOCK WASHER | KOB |
| 17. | ZX20H12072 | [1] | HOSE ASSY. | KOBHose |
| 18. | ZH32X08000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow |
