纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (139-18[1]) - PEDAL ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1018 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT55M00007F1 | [1] | Pedal Assy | |
| 1. | YY26M00022P1 | [1] | FLOOR MAT | KOB |
| 2. | YY26M00021P1 | [1] | FLOOR MAT | KOB |
| 3. | YY55M01030P1 | [1] | PEDAL | KOB |
| 4. | YT55M01065P1 | [1] | PEDAL | KOB Superseded by part number: YT55M01065P3 |
| 5. | YY55M01022P1 | [1] | FLEXIBLE HOSE | KOBRubber Superseded by part number: YY55M01022P2 |
| 6. | YN03M01858P1 | [1] | RUBBER PEDAL PAD | SM |
| 7. | YY55M01034P1 | [1] | LOCK | KOBAssy |
| 8. | YT55M01069F1 | [1] | Lock Assy | |
| 8-1. | YT55M01068P1 | [1] | LEVER | KOB Superseded by part number: YT55M01075F1 |
| 8-2. | 2405R312D1210 | [2] | BUSHING | KOB |
| 8-3. | YT55M01052P1 | [1] | BAR | KOB |
| 8-4. | YT55M01053P1 | [1] | BAR | KOB |
| 8-5. | ZP26K02512 | [1] | PIN | KOBSpring |
| 9. | YY55M01027P1 | [1] | PIN | KOBStopper |
| 10. | YT55M01067P1 | [1] | PLATE | KOB |
| 11. | ZM73C08020 | [8] | BOLT,M8x20mm - Course Thread | KOBSems |
| 12. | ZM73C10020 | [2] | BOLT,M10x20mm - Course Thread | KOBSems |
| 13. | ZM73C10016 | [2] | BOLT,M10x16mm - Course Thread | KOBSems |
