| 1. |
6383
|
[2] |
PIN
|
FLX
|
| 2. |
43140
|
[80] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 3. |
43144
|
[2] |
BOLT,Hex, M10 x 70mm, Cl 8.8
|
NH
Superseded by part number: 87015537
|
| 4. |
100037
|
[44] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 5. |
120070
|
[12] |
BOLT,Hex, M10 x 1.5 x 60mm, Cl 8.8
|
NH
|
| 6. |
300388
|
[8] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 7. |
337475
|
[8] |
NUT,M12, Cl 10
|
BHB
|
| 8. |
BRR1768926
|
[8] |
SCREW,Hex, M6 x 1 x 110mm, Cl 8.8
|
BRR
|
| 9. |
9804276
|
[8] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 10. |
10734101
|
[2] |
COTTER PIN,M1.6 x 12
|
BAS
Superseded by part number: 87016658
|
| 11. |
18711611
|
[4] |
NUT
|
GI
|
| 12. |
12644301
|
[2] |
WASHER,M10 x 35 x 3
|
TTF
Superseded by part number:
|
| 13. |
13790921
|
[2] |
SET SCREW,Hex Skt, M6 x 6mm, Cl 8.8, Full Thd, Flat Pt
|
BAS
|
| 14. |
47357790
|
[30] |
SEAL
|
SAS
Inter Meter
|
| 15. |
47625036
|
[2] |
WIRE HARNESS
|
SAS
Air Cart, 10 Motors
|
| 16. |
47715237
|
[4] |
SENSOR
|
SAS
Meter Control
|
| 17. |
47715783
|
[8] |
SENSOR
|
SAS
Meter Control
|
| 18. |
47692065
|
[8] |
DEFLECTOR
|
SAS
Sub Hopper
|
| 19. |
47357732
|
[12] |
MODULE
|
SAS
Meter, Motor, Coarse Superseded by part number: 47891163
|
| 19. |
47891162
|
[12] |
METER
|
SAS
Meter, Motor, Extra Fine
|
| 20. |
47886361
|
[2] |
MOTOR-PUMP
|
SAS
|
| 21. |
86511953
|
[8] |
BOLT,Hex Serr, M6 x 25mm
|
WIN
|
| 22. |
47761491
|
[2] |
COLLAR
|
SAS
Locking
|
| 23. |
47775957
|
[2] |
LINKAGE
|
SAS
Meter Shutoff
|
| 24. |
47775958
|
[2] |
LUG
|
SAS
Swivel Connector
|
| 25. |
47775966
|
[2] |
SHAFT
|
SAS
Handle Mount
|
| 26. |
47775967
|
[2] |
BRACKET
|
SAS
Backing Plate
|
| 27. |
47767919
|
[2] |
HANDLE
|
SAS
Meter Shutoff
|
| 28. |
6636
|
[2] |
BUSHING
|
CAS
Superseded by part number: 87420247
|
| 29. |
47775970
|
[2] |
BRACKET
|
SAS
Handle Lock
|
| 30. |
47779900
|
[4] |
CROSSRAIL
|
SAS
Narrow Meter
|
| 31. |
47779925
|
[2] |
BRACKET
|
SAS
Meter End Plate
|
| 32. |
47901543
|
[2] |
DECAL
|
SAS
Master Shut Off
|
| 33. |
47780093
|
[2] |
COVER
|
SAS
Narrow Meter W/ Seal and Latch
|
| 34. |
84062222
|
[32] |
BOLT,Hex, M10 x 45mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 8900127036
|
| 35. |
86500689
|
[80] |
NUT,M10 x 1.5, Cl 10
|
NH
|
| 36. |
86588450
|
[8] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 37. |
86625253
|
[144] |
WASHER,11mm ID x 24mm OD x 2mm Thk
|
FAR
|
| 38. |
86639011
|
[4] |
CLAMP,19mm, Coat, 10.3mm Bolt Hole, J Type
|
FAR
|
| 39. |
87016663
|
[2] |
CLEVIS PIN,M8 x 30
|
DUB
|
| 40. |
48011430
|
[72] |
SCREW
|
SAS
|
| 41. |
86512915
|
[24] |
LOCK WASHER,Int Tooth, 7/16"
|
NH
|
