| . . | YT06H00049F1 | [1] | Control Lines, Main | |
| A1. | 2420R349D048 | [1] | HOSE ASSY. | KOB, Serial Range: LF05-04001-LF05-04132 Superseded by part number: 2420R349D050 |
| A3. | 2420R349D125 | [1] | HOSE,1250.00 mm | KOB Superseded by part number: HX21E04125DX |
| A4. | 2444R963D38 | [2] | FLEXIBLE HOSE | KOB |
| A6. | 2444Z2894 | [2] | 90 ELBOW | KOBElbow |
| A7. | ZH32X04000 | [12] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, Serial Range: LF05-04001-LF05-04132 |
| A8. | YT42H01128P1 | [2] | ELBOW | KOB, Serial Range: LF05-04001-LF05-04132 |
| A9. | ZH42X04000 | [2] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| A10. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| A11. | ZH32X04006 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB, Serial Range: LF05-04001-LF05-04132 |
| A12. | 2444T2529 | [1] | TEE | KOB, Serial Range: LF05-04001-LF05-04132 |
| A13. | 2444Z2336 | [1] | HYD CONNECTOR | KOBTee |
| A14. | 2444Z2461 | [3] | TEE | KOB |
| A15. | 2444Z2525 | [6] | HYD CONNECTOR | KOB, Serial Range: LF05-04001-LF05-04132 |
| A16. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A17. | YX52S00013P1 | [2] | SENSOR | SMPress (L.P.) Superseded by part number: LC52S00019P1 |
| A17-2. | ZD12P01100 | [1] | O-RING | KOB |
| A18. | YT06H01019P1 | [1] | GUIDE | KOBGuide |
| A19. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOB, Serial Range: LF05-04001-LF05-04132 |
| A20. | ZM73C12025 | [1] | BOLT,M12x25mm - Course Thread | KOBSems |
| A21. | HH55Q06006G1 | [1] | TEE | KOB, Serial Range: LF05-04001-LF05-04132 |
| A22. | HX33L04048DY | [1] | FLEXIBLE HOSE | KOB, Serial Range: LF05-04001-LF05-04132 |
| A23. | ZH22X04006 | [1] | HYD CONNECTOR | KOB, Serial Range: LF05-04001-LF05-04132 |
| A24. | HH35X04004G3 | [1] | 90 ELBOW | KOB(with Filter) |
| A25. | 2444R596D1 | [1] | ELBOW | KOB |
| A26. | PH62H01003P1 | [1] | ELBOW | KOB(with Filter) Superseded by part number: 72283832 |
| A27. | PF21V00006P1 | [1] | CHECK VALVE | KOB |
| A28. | 2444Z4473 | [1] | HYD CONNECTOR | KOB |
| A29. | YY21V00001F1 | [1] | CHECK VALVE | KOBAssy |
| A30. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
| A31. | PW21P01003DH | [1] | Tube, Serial Range: LF05-04001-LF05-04132 | |
| A32. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB, Serial Range: LF05-04001-LF05-04132 |
| A33. | ZE72X04000 | [1] | PLUG | KOB, Serial Range: LF05-04001-LF05-04132 |
| A34. | YT06H1023P1 | [1] | Tee, Start Serial: LF05-04133 | |
| . . | YT06H00041F1 | [1] | TUBE | KOBControl Lines, Main |
| B1. | ZE72X06000 | [1] | PLUG | KOB |
| . . | YT06H00054F1 | [1] | TUBE | KOBControl Lines, Main |
| C1. | 2444R963D34 | [1] | FLEXIBLE HOSE | KOB |
| C2. | 2444R963D19 | [1] | FLEXIBLE HOSE | HIT |
| C3. | 2444R963D28 | [1] | FLEXIBLE HOSE | KOB Superseded by part number: HX31E04025DX |
| C4. | 2444Z2544 | [1] | TEE | KOB |
| . . | YT06H00097F1 | [1] | Control Lines, Valve | |
