纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (152-17[2]) - CONTROL LINES, VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
135 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LF64H00024F1 | [1] | Control Lines, Valve | |
| . . | LF64H00016F1 | [1] | TUBE | KOBControl Lines, Valve |
| 1. | YT35V00027F1 | [1] | SOLENOID VALVE | KOBAssy |
| 2. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB, Serial Range: LF05-04001-LF05-04132 |
| 3. | 2420R537D130 | [1] | HOSE,9.60mm ID x 1300mm L | KOB Superseded by part number: HX21E06130DX |
| 4. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| 6. | 2420R349D210 | [1] | FLEXIBLE HOSE | KOB |
| 7. | 2420R537D086 | [1] | HOSE,9.60mm ID x 860mm L | KOB Superseded by part number: 2420R537D090 |
| 8. | 2420R537D110 | [1] | HOSE ASSY.,9.60mm ID x 1100mm L | KOB Superseded by part number: HX21E06110DX |
| 9. | 2420R537D240 | [1] | HOSE,9.53mm ID x 2400mm L | KOB |
| 10. | LF64H01004D1 | [1] | FLEXIBLE HOSE | KOB |
| 11. | YT42H01128P1 | [1] | ELBOW | KOB |
| 12. | 2444Z3279 | [1] | 90 ELBOW | KOB |
| 13. | ZH32X04000 | [4] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, Serial Range: LF05-04001-LF05-04132 |
| 14. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow |
| 15. | PH03H01066P1 | [1] | TEE | KOB |
| 17. | 2444Z2525 | [1] | HYD CONNECTOR | KOB, Serial Range: LF05-04001-LF05-04132 |
| 18. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| 19. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| 20. | YN50V00020F1 | [1] | HYDRAULIC OIL FILTER | SMFilter Assy, Inline |
| 21. | EW02E01015D4 | [1] | CLIP | KOB |
| 22. | PY01P01043D8 | [6] | CABLE TIE,102mm L | KOB, Serial Range: LF05-04001-LF05-04132 |
| 23. | YN13E01375P1 | [3] | CLIP,M8 x 8.20mm Shank | KOB |
| 24. | ZS18C08080 | [2] | SCREW,Hex, M8 x 80mm | KOBCap |
| 25. | ZW16H08000 | [2] | WASHER | KOB |
| 26. | ZE72X04000 | [1] | PLUG | KOB, Serial Range: LF05-04001-LF05-04132 |
| . . | YT64H00105F1 | [1] | Control Lines, Valve | |
