纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (155-01[1]) - CONTROL LINES, PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
638 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2420R349D068 | [1] | HOSE | KOB |
| 3. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow |
| 5. | ZH42X04000 | [2] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| 7. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 8. | ZC45X46014 | [1] | CLIP | KOBClip Superseded by part number: ZC46X46014 |
| 11. | YX32H01011P1 | [1] | BUSHING,33mm ID x 49mm OD x 50mm L | KOB |
| 12. | ZE72X04000 | [1] | PLUG | KOB |
| 13. | YT22V00013F1 | [1] | PRESSURE RELIEF VALVE | KOBAssembly, Incl 13-1 & 13-2 |
| 13-1. | YT22V00014F1 | [1] | PRESSURE RELIEF VALVE | KOB |
| 13-2. | YT22V00013S002 | [1] | BLOCK | KOB |
| 14. | YT06H01024D1 | [1] | HYDRAULIC HOSE | KOB |
| 15. | 2420R349D130 | [1] | FLEXIBLE HOSE | KOB |
| 16. | 2444R941D12 | [1] | FLEXIBLE HOSE | KOB |
| 17. | ZH22X06008 | [1] | HYD CONNECTOR | KOB |
| 18. | ZH32X04000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| 19. | HH35X04004G3 | [1] | 90 ELBOW | KOB(with Filter) |
| 20. | YT42H01128P1 | [1] | ELBOW | KOB |
| 21. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow |
| 22. | 2444R596D2 | [1] | ELBOW | KOB |
| 23. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB |
| 24. | ZS18C08065 | [1] | SCREW,Hex, M8 x 65mm | KOBCap |
| 25. | ZW16H08000 | [1] | WASHER | KOB |
| 26. | 2414Z199D130 | [1] | GUARD | KOBHose, Guard |
