纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (160-01[1]) - CONTROL LINES, PROPEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
987 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT62H00006F1 | [1] | Control Lines, Propel | |
| . . | YT62H00007F1 | [1] | Control Lines, Propel | |
| A1. | YN30V00070F1 | [1] | VALVE | KOBAssy, Pilot, Serial Range: LF05-04001-LF05-04181 Superseded by part number: YN30V00070F2 |
| . . | YN30V00070F2 | [1] | PILOT VALVE | KOBValve Assy, Pilot, Start Serial: LF05-04182 |
| A2. | 2420R349D082 | [2] | HYDRAULIC HOSE,6.35 mm ID x 820.00 mm | KOB Superseded by part number: 2420R349D085 |
| A3. | 2420R349D210 | [2] | FLEXIBLE HOSE | KOB |
| A4. | 2420R349D240 | [2] | HOSE,2400.00 mm | KOB Superseded by part number: HX21E04240DX |
| A5. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB(with Filter) |
| A6. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB |
| A7. | YF62H01001P1 | [4] | RUBBER BAND | KOB |
| A8. | ZM73C08025 | [4] | BOLT,M8x25mm - Course Thread | KOBSems |
| A9. | YX52S00013P1 | [2] | SENSOR | SMPress (L.P.) Superseded by part number: LC52S00019P1 |
| A9-2. | ZD12P01100 | [1] | O-RING | KOB |
| . . | YT62H00008F1 | [1] | TUBE | KOBControl Lines, Propel |
| B1. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| B2. | ZH32X04000 | [4] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow |
| . . | YF64H00055F1 | [1] | Control Lines, Block | |
| C1. | YN64H01336P1 | [1] | BLOCK | KOB |
| C2. | ZM73C08020 | [3] | BOLT,M8x20mm - Course Thread | KOBSems |
