纽荷兰零件查询(E80BMSR) - CRAWLER EXCAVATOR ASN LF05-04001 - (N8TA18060) (175-17[1]) - MIRROR INSTAL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
993 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT52C00012F3 | [1] | Mirror Instal | |
| 1. | YT52C00006P1 | [1] | MIRROR,210mm x 210mm | KOB |
| 2. | YT52C01070P1 | [1] | STAY | KOB |
| 3. | ZM73C10020 | [3] | BOLT,M10x20mm - Course Thread | KOBSems |
| 5. | YT52C01023P1 | [1] | STAY | KOB |
| 6. | YN02C01762P1 | [1] | BRACKET | KOB |
| 7. | ZW16H10000 | [2] | WASHER | KOB |
| 8. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 9. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBCap |
| 10. | ZW16X12000 | [2] | WASHER | KOB |
| 11. | R16T0137D1 | [2] | WASHER | KOB |
| 12. | ZN18C12010 | [6] | NUT | KOB |
| 13. | PY02C01079P1 | [1] | MIRROR | KOBAssy, Back |
| 14. | YN02C01121P1 | [1] | MIRROR | KOB |
| 15. | ZM46C05016 | [3] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBSems |
| 16. | 2420R574D10 | [3] | NUT | KOB |
