| . . | 24100J6672F1 | [1] | MOUNTING PARTS | KOBMOTOR ASSY, SWING Superseded by part number: 24100J6672F6 |
| . . | 24100J6672F2 | [1] | MOTOR ASSY, SWING | |
| . . | 24100J6672F3 | [1] | MOTOR ASSY, SWING | |
| . . | 24100J6672F4 | [1] | MOTOR ASSY, SWING | |
| . . | 24100J6672F5 | [1] | MOTOR ASSY, SWING | |
| 1. | 2401N436 | [1] | FINGER ASSY. | KOB |
| 2. | 2418T19344 | [1] | SLEEVE | KOBF1, F2 ONLY Replaces 2418T17393 |
| 3. | 2418N4705 | [1] | RETAINER | KOBF1, F2 ONLY Replaces Pn 2418N2314 |
| 4. | 2414J1049 | [1] | HOUSING, F1 - F4 ONLY | |
| 5. | 2425Z490 | [1] | BEARING | KOB |
| . . | R25P0047D8 | [1] | BEARING | KOBROLLER |
| 6. | 25Z494D11 | [1] | BEARING | KOB |
| 7. | 2413J350 | [1] | DIFF. SPIDER | KOBSPIDER |
| 8. | 2413N391F1 | [1] | SPIDER | KOB |
| S. | 2410P694 | [4] | ROLLER SHAFT | KOB |
| 10. | 2401N431 | [1] | GEAR | KOB |
| 11. | 2401P624 | [1] | SUN GEAR | KOB |
| 12. | 2401P625 | [4] | PINION | KOB |
| 13. | 2401P627 | [4] | PINION | KOBPLANETARY |
| 14. | ZD11G09500 | [1] | O-RING,94.40mm ID x 100.60mm OD x 3.10mm | KOBID 94.40 ± 0.81 x OD 100mm |
| 15. | ZS23C08030 | [12] | SCREW,Hex Socket Head, M8 x 30mm | KOBM08x1.25x30mm Superseded by part number: ZS28C08030 |
| 17. | 2418T13612 | [1] | SPACER | KOB |
| 18. | 2418T12561 | [2] | SPACER | KOB |
| 19. | 2401P626 | [1] | SUN GEAR | KOB |
| 20. | ZR16X04500 | [5] | RING | KOBRetaining -- ID 45 x OD 58 x Th 1.8mm |
| 21. | 2418T7535 | [4] | THRUST WASHER | KOB |
| 22. | 2418T8322 | [4] | THRUST WASHER | KOB |
| 23. | 2418T7513 | [4] | LOCKING PLATE | KOB |
| 24. | ZS23C08014 | [8] | SCREW,Hex Socket Head, M8 x 14mm | KOBM08x1.25x14mm |
| 25. | ZR16X08500 | [1] | LOCKING RING | KOB |
| 26. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
| 27. | 2418T5452 | [8] | THRUST WASHER | KOB |
| 28. | 2418T17425 | [1] | PIPE | PIPE |
| . . | 2418T17425D2 | [1] | PIPE | |
| 29. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 30. | 2418T17394 | [1] | SPACER | KOB |
| 31. | 2441U755F1 | [1] | HYDRAULIC MOTOR | KOBSWING |
| 31-1. | 2436U1167F1 | [1] | CONTROL VALVE | KOB |
| 31-2. | 2441U758F1 | [1] | MOTOR | KOB |
| 31-3. | ZS23C12110 | [8] | SCREW,Hex Socket Head, M12 x 110mm | KOBM12x1.75x110mm Superseded by part number: ZS28C12110 |
| 31-4. | ZD12G03500 | [2] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 31-5. | 2436U1283F1 | [1] | VALVE PRESSURE RELIE | KOB |
| 32. | ZS23C14140 | [10] | SCREW,Hex Socket Head, M14 x 140mm | KOBM14x2.0x140mm |
| 33. | 2418T18051 | [1] | SLEEVE F3, F4 ONLY | SLEEVE F3, F4 ONLY |
| 34. | 2418N4627 | [1] | RETAINER F3, F4 ONLY | RETAINER F3, F4 ONLY |
| 35. | 2427T902 | [1] | PROTECTOR | KOBF3, F4 ONLY |
| 36. | 2418R245 | [1] | OIL SEAL | KOBF2, F4 ONLY Replaces Pn 2418R236 |
| . . | 2418R245 | [1] | OIL SEAL | KOBF2,F2, F5 ONLY |
| 37. | 2418T19344 | [1] | SLEEVE | KOBF5 ONLY |
| 38. | 2418N4704 | [1] | RETAINER F5 ONLY | RETAINER F5 ONLY |
| 39. | 2414J1915 | [1] | HOUSING F5 ONLY | HOUSING F5 ONLY |
| 40. | 2418T17425D2 | [1] | PIPE, F5 ONLY | |
| 50. | 2418T18132 | [1] | SPACER SERVICE KIT PART NO. | SPACER SERVICE KIT PART NO. |
| 51. | 2414T2977 | [1] | COVER | KOBSERVICE KIT PART NO. |
| . . | 24100J9301F1 | [1] | REDUCER | KOB(SERVICE KIT), CONSISTS OF REF 1 - 15, 17 - 30, 32, 36, 50, 51 Superseded by part number: 24100J9301F5 |
| . . | 24100J9301F2 | [1] | REDUCTION UNIT (SERVICE KIT), CONSISTS OF REF 1, 4 - 30, 32 - 35, 50, 51 | |
| . . | 24100J9301F3 | [1] | REDUCER | KOB(SERVICE KIT), CONSITS OF REF 1, 4 - 15, 17 - 30, 32 - 36, 50, 51 Superseded by part number: 24100J9301F5 |
