凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (61.904.AD[03]) - FRAME, ROLLER CARTRIDGE, EXTRA FINE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
825 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47795912
|
[1] |
ROLLER
|
SAS
Meter Roller Cartridge, White Incl 4
|
| 2. |
47357741
|
[1] |
ROLLER
|
SAS
Meter Service, Incl 6
|
| 3. |
47357749
|
[1] |
KNOB
|
SAS
Cartridge Locking
|
| 4. |
47668782
|
[2] |
O-RING
|
SAS
Roller Cartridge
|
| 5. |
86511
|
[2] |
O-RING,0.07" Thk x 1.364" ID, -28, Cl 5, 75 Duro
|
WIN
|
| 6. |
47357750
|
[1] |
BEARING ASSY
|
SAS
|
| 7. |
47788127
|
[1] |
SUPPORT
|
SAS
Cartridge Brace
|
