神钢零件查询(MD200BLC) - EXCAVATOR BTW YQ0101 - YQ0564 (1/80-12/06) (02-007) - COVER ASSY, UNDER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
319 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J6626F2 | [1] | COVER ASSY, UNDER | COVER ASSY, UNDER |
| 3. | 2414P6035 | [1] | COVER | KOB |
| 4. | 2414P6036 | [1] | COVER | KOB |
| 5. | 2414T2891 | [1] | COVER | KOB |
| 7. | ZS18C12030 | [33] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 8. | 2418T10357 | [33] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 9. | ZW26X12000 | [33] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 10. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 12. | 2414P6053 | [1] | COVER | COVER |
| 13. | 2414P6052 | [1] | COVER | KOB |
| 14. | 2414P4045 | [1] | COVER | KOB |
