| 1. |
47739491
|
[1] |
MOUNT
|
SAS
Aux Fill Black
|
| 2. |
47741213
|
[1] |
MOUNT
|
SAS
Aux Fill Black
|
| 3. |
47534143
|
[4] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
M16
|
| 4. |
146988
|
[8] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 5. |
47741731
|
[1] |
FRAME
|
SAS
Rotary Housing
|
| 6. |
43140
|
[8] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
|
| 7. |
8475948
|
[8] |
NUT,M10 x 1.5, Cl 8
|
BER
Superseded by part number: 100037
|
| 8. |
87030508
|
[2] |
BOLT,Hvy Hex, M12 x 30mm, Full Thd, Cl 10.9
|
GI
|
| 9. |
9804279
|
[2] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 10. |
86988929
|
[1] |
INTAKE AIR HOSE
|
SAS
Bulk 25 Foot 6" Dia Cut To Length
|
| 11. |
87690486
|
[2] |
CLAMP,149mm ID - 172mm ID, SAE #100
|
GI
|
| 12. |
296823A2
|
[1] |
VALVE
|
CAS
Flow Control
|
| 13. |
16045321
|
[2] |
BOLT,Hex, M8 x 1.25 x 105mm, Cl 8.8
|
MKT
|
| 14. |
68841
|
[2] |
NUT,M8 x 1.25, Cl 8
|
BER
Superseded by part number: 16104414
|
| 15. |
128819
|
[1] |
HYD CONNECTOR,7/8" - 14 ORB x 3/4" - 16 JIC
|
BHB
|
| 16. |
322894
|
[2] |
90 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
BHB
|
| 17. |
144124
|
[1] |
HYD CONNECTOR,1-1/16" - 12 JIC x 7/8" - 14 ORB
|
WIN
|
| 18. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 19. |
219603
|
[1] |
90 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12, 37 Degree Fem Sw
|
BHB
|
| 20. |
86526
|
[1] |
ELBOW,90 Degree, 37 Degree 9/16" - 18 JIC x 9/16" - 18 ORB
|
FOR
|
| 21. |
87411460
|
[1] |
REDUCER
|
SAS
Adapter Tube
|
| 22. |
47743946
|
[1] |
HYDRAULIC HOSE
|
SAS
10 x 2032 mm
|
| 23. |
87557086
|
[2] |
CABLE TIE
|
SAS
30"
|
| 24. |
47679558
|
[4] |
HOSE, BULK
|
SAS
100 Foot 2.5 PVC
|
| 25. |
47743945
|
[1] |
HYDRAULIC HOSE
|
SAS
13 x 4470 mm
|
| 26. |
86050197
|
[8] |
HOSE CLAMP,58.6mm - 82.5mm, Worm Gear
|
FOR
|
| 27. |
87599630
|
[1] |
VALVE
|
BN
2 Way Manual
|
| 28. |
47798412
|
[1] |
FEEDER
|
SAS
Arm
|
| 29. |
495-11053
|
[2] |
WASHER,1/2", SAE
|
CAS
Superseded by part number: 87364, 72187259
|
| 30. |
7058
|
[1] |
WASHER,1/4", SAE
|
FLX
Superseded by part number: 87361
|
| 31. |
86632597
|
[1] |
BOLT,M5 x 0.8 x 15.65mm, Cl 8.8
|
FAR
|
| 32. |
86508567
|
[2] |
BOLT,Hex, M5 x 45mm, Cl 8.8
|
NH
|
| 33. |
2977215
|
[2] |
NUT,M5 x 0.8, Cl 8
|
BER
Superseded by part number: 80043440
|
| 34. |
21577
|
[1] |
FITTING
|
SAS
Superseded by part number: 87412765
|
| 35. |
87423032
|
[1] |
SHUT-OFF VALVE
|
BUR
Needle
|
| 36. |
76344
|
[2] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 37. |
86632548
|
[2] |
TEE,37 Degree, 7/8"-14 x 3/4"-16, Fem Sw Run x 3/4"-16 Br
|
FOR
|
| 38. |
86624135
|
[2] |
REDUCER,37 Degree, 3/4"-16, Fem x 9/16"-18 Male
|
FOR
|
| 39. |
47798383
|
[1] |
HYDRAULIC HOSE
|
SAS
6.3 x 430 mm
|
| 40. |
47798384
|
[1] |
HYDRAULIC HOSE
|
SAS
6.3 x 500 mm
|
| 41. |
47798386
|
[1] |
HYDRAULIC HOSE
|
SAS
6.3 x 730 mm
|
