凯斯零件查询(2355) - PRECISION AIR CART (11/15-) (77.100.XX[01]) - CONVEYOR HYDRAULIC CONTROL 580 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
200 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47918693
|
[1] |
CONVEYOR
|
SAS
Assy, Incl 2 - 42
|
| 2. |
47753157
|
[1] |
HYDRAULIC CYLINDER
|
SAS
Cylinder Main 580
|
| 3. |
47854837
|
[1] |
ARM
|
SAS
Main
|
| 4. |
87505171
|
[1] |
HYDRAULIC CYLINDER,31.75mm Rod, 406.4mm Stroke
|
SAS
Lift Superseded by part number: 47582359
|
| 5. |
47855569
|
[1] |
BRACKET
|
SAS
Parallel Arms
|
| 6. |
47753687
|
[1] |
PIN
|
SAS
Pin
|
| 7. |
47753126
|
[1] |
HYDRAULIC CYLINDER
|
SAS
Support, Incl 44
|
| 8. |
47855678
|
[1] |
CAM
|
SAS
Arm
|
| 9. |
47761856
|
[1] |
HYDRAULIC CYLINDER
|
SAS
Cylinder Cam
|
| 10. |
47857140
|
[1] |
BRACKET
|
SAS
Head Transport
|
| 11. |
47753128
|
[1] |
HYDRAULIC CYLINDER
|
SAS
Incl 43
|
| 12. |
47892210
|
[1] |
SHELL
|
SAS
Clam
|
| 13. |
47879564
|
[1] |
CAM
|
SAS
Brace
|
| 14. |
47753137
|
[1] |
BUSHING
|
SAS
Cam Track
|
| 15. |
47879553
|
[1] |
BUSHING
|
SAS
Cam Track
|
| 16. |
47753688
|
[1] |
PIN
|
SAS
Support
|
| 17. |
47879396
|
[1] |
BUSHING
|
SAS
|
| 18. |
86511191
|
[4] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 19. |
47857863
|
[1] |
PIN
|
SAS
|
| 20. |
47857864
|
[1] |
PIN
|
SAS
|
| 21. |
47857861
|
[1] |
PIN
|
SAS
|
| 22. |
87374
|
[6] |
WASHER,1.06" ID x 2.5" OD x 0.17" Thk
|
NH
|
| 23. |
88381
|
[1] |
BOLT,Hex, 1" - 8 x 5", Gr 5
|
FOR
|
| 24. |
47879562
|
[1] |
PIN
|
SAS
Cam Bushing
|
| 25. |
280286
|
[1] |
NUT,1"-8, GB
|
NH
|
| 26. |
47753685
|
[1] |
PIN
|
SAS
Conveyor
|
| 27. |
47879555
|
[1] |
CAM
|
SAS
Brace
|
| 28. |
47879557
|
[1] |
CAM
|
SAS
Brace Bottom Pad
|
| 29. |
120115
|
[2] |
BOLT,M10 x 1.5 x 76.58mm, Cl 8.8
|
NH
|
| 30. |
8475948
|
[2] |
NUT,M10 x 1.5, Cl 8
|
BER
Superseded by part number: 100037
|
| 31. |
47887235
|
[2] |
PIN
|
SAS
Superseded by part number: 47887245
|
| 32. |
47887245
|
[4] |
PIN
|
SAS
|
| 33. |
80708
|
[2] |
COTTER PIN,1/8" x 1 1/2"
|
NH
|
| 34. |
88182
|
[4] |
COTTER PIN,1/4" OD x 2" L
|
NH
|
| 35. |
47851765
|
[10] |
CLAMP
|
SAS
3/4"
|
| 36. |
47879505
|
[20] |
CLAMP
|
SAS
|
| 37. |
47887748
|
[7] |
CLAMP
|
SAS
|
| 38. |
189298
|
[3] |
BOLT,Hex, 5/16" - 18 x 4", Gr 5
|
IH
Superseded by part number: 88964
|
| 39. |
47879515
|
[2] |
CLAMP
|
SAS
|
| 40. |
9636711
|
[2] |
BOLT,Hex, 5/16 - 18" x 2", Gr 5
|
NH
|
| 41. |
87657
|
[4] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
NH
|
| 42. |
47753693
|
[1] |
MOUNT
|
SAS
Arm Cam
|
| 43. |
47466076
|
[1] |
SEAL KIT
|
BU
Hydraulic Cylinder Superseded by part number: 47430171
|
| 44. |
47923231
|
[1] |
SEAL KIT
|
SAS
Hydraulic Cylinder
|
