| 1. |
87657
|
[7] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
NH
|
| 2. |
86505972
|
[1] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 3. |
87375
|
[2] |
WASHER,1.5" ID x 3.25" OD x 0.18" Thk
|
GI
|
| 4. |
76344
|
[2] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 5. |
9479
|
[1] |
PLUG
|
SAS
|
| 6. |
84313
|
[1] |
ELBOW,45 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring
|
WIN
|
| 7. |
47705045
|
[2] |
BRACKET
|
SAS
Mount
|
| 8. |
47818624
|
[2] |
U-BOLT
|
SAS
|
| 9. |
86625263
|
[4] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 10. |
9706690
|
[4] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 11. |
84536987
|
[1] |
PACKAGE
|
SAS
|
| 12. |
8258
|
[8] |
SELF-TAP SCREW,Phillips Drive, Pan Head, #8 - 32 x 3/8"
|
FLX
|
| 13. |
47697609
|
[1] |
WIRE HARNESS
|
SAS
Air Cart Superseded by part number: 47960646
|
| 14. |
84556425
|
[1] |
VALVE
|
SAS
Auger Control
|
| 15. |
330344
|
[2] |
45 ELBOW,1-1/16" - 12 JIC x 1-1/16" - 12 ORB
|
WIN
|
| 16. |
84555687
|
[6] |
HYD CONNECTOR
|
SAS
|
| 17. |
322896
|
[2] |
HYD CONNECTOR,1-1/16" - 12 ORB x 1-1/16" - 12 JIC
|
BHB
|
| 18. |
367841A1
|
[1] |
ELBOW
|
CAS
Orifice
|
| 19. |
83918746
|
[2] |
WASHER,0.34" ID x 0.69" OD x 0.07" Thk
|
FOR
Superseded by part number: 44722S36
|
| 20. |
412110
|
[2] |
BOLT,Hex, M8 x 1.25 x 170mm, Cl 8.8
|
NH
Superseded by part number: 8900129024
|
| 21. |
86629542
|
[2] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 22. |
47734997
|
[1] |
SUPPORT
|
SAS
Valve Block
|
| 23. |
47864584
|
[1] |
HOSE
|
SAS
1/4" X 212"
|
| 24. |
47864577
|
[1] |
HOSE
|
SAS
1/4" X 141"
|
| 25. |
47864537
|
[2] |
HOSE
|
SAS
.75 X 243"
|
| 26. |
47864572
|
[1] |
HOSE
|
SAS
1/4" X 89"
|
| 27. |
47864573
|
[1] |
HOSE
|
SAS
1/4" X 103"
|
| 28. |
47864580
|
[1] |
HOSE
|
SAS
1/4" X 49"
|
| 29. |
47864581
|
[1] |
HOSE
|
SAS
1/4' X 34"
|
| 30. |
47864583
|
[1] |
HOSE
|
SAS
1/4" X 204"
|
| 31. |
47864463
|
[2] |
HOSE
|
SAS
.75" X135"
|
| 32. |
47866055
|
[1] |
TUBE
|
SAS
Rubber Flex 12"
|
| 33. |
47866057
|
[1] |
CLAMP
|
SAS
12" T-Bolt
|
| 34. |
47879396
|
[1] |
BUSHING
|
SAS
|
| 35. |
47876148
|
[1] |
STEP
|
SAS
Anti Slip Tape
|
| 36. |
47686594
|
[1] |
MOTOR-PUMP
|
SAS
8.0 Cu Inch 1 Inch Shaft
|
| 37. |
47880827
|
[1] |
BELT
|
SAS
BELT, 19" RUBB. CRESCT, SKIVED - 9'10"
|
| 38. |
47880781
|
[1] |
BELT
|
SAS
BELT ASSY, 19" PVG 2.25" CLEATED, 5" CLEAT SPACING,48' 9"
|
