| 1. |
47685636
|
[1] |
QUICK-HITCH
|
SAS
Frame Mount
|
| 2. |
11119231
|
[14] |
BOLT,M16 x 75mm, Cl 10.9
|
MKT
Superseded by part number: 11119274
|
| 3. |
146988
|
[16] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 4. |
47752026
|
[1] |
BRACKET
|
SAS
760/950 Head Transport Assy
|
| 5. |
84439252
|
[2] |
BOLT,Hex, M16 x 150mm, Cl 10.9
|
RAC
|
| 6. |
47750608
|
[1] |
MOUNT
|
SAS
Cylinder Mount
|
| 7. |
47751309
|
[1] |
SHELL
|
SAS
Lower Conveyor Clamp 760/950
|
| 8. |
87505171
|
[1] |
HYDRAULIC CYLINDER,31.75mm Rod, 406.4mm Stroke
|
SAS
Superseded by part number: 47582359
|
| 9. |
47887245
|
[6] |
PIN
|
SAS
|
| 10. |
76347
|
[4] |
ELBOW,90 Degree, 9/16" - 18 JIC x 3/4" - 16 ORB
|
NH
Superseded by part number: 87329788
|
| 11. |
47686466
|
[1] |
ARM
|
SAS
Main Assy
|
| 12. |
47761848
|
[1] |
PIN
|
SAS
Main Hinge
|
| 13. |
120115
|
[2] |
BOLT,M10 x 1.5 x 76.58mm, Cl 8.8
|
NH
|
| 14. |
8475948
|
[2] |
NUT,M10 x 1.5, Cl 8
|
BER
Superseded by part number: 100037
|
| 15. |
47857774
|
[1] |
ARM
|
SAS
Parallel 760/950
|
| 16. |
47879505
|
[18] |
CLAMP
|
SAS
.25 Twin Hose
|
| 17. |
47851765
|
[10] |
CLAMP
|
SAS
.75 Twin Hose
|
| 18. |
47879515
|
[5] |
CLAMP
|
SAS
|
| 19. |
47887748
|
[8] |
CLAMP
|
SAS
|
| 20. |
9636711
|
[5] |
BOLT,Hex, 5/16 - 18" x 2", Gr 5
|
NH
|
| 21. |
413-522
|
[7] |
BOLT,Hex, 5/16" - 18 x 1-3/8", Gr 5
|
CAS
|
| 22. |
86505972
|
[1] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 23. |
47761849
|
[1] |
PIN
|
SAS
Hinge Elbow
|
| 24. |
47857790
|
[1] |
SUPPORT
|
SAS
Cam Assy 760/950 Incl 51-53
|
| 25. |
47916714
|
[1] |
HYDRAULIC CYLINDER
|
SAS
|
| 26. |
76344
|
[2] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 27. |
47753137
|
[1] |
BUSHING
|
SAS
Cam Track
|
| 28. |
47879553
|
[1] |
BUSHING
|
SAS
Polygon
|
| 29. |
47857861
|
[1] |
PIN
|
SAS
Cam
|
| 30. |
87374
|
[6] |
WASHER,1.06" ID x 2.5" OD x 0.17" Thk
|
NH
|
| 31. |
88182
|
[6] |
COTTER PIN,1/4" OD x 2" L
|
NH
|
| 32. |
47879562
|
[1] |
PIN
|
SAS
Spacer, Cam
|
| 33. |
88381
|
[1] |
BOLT,Hex, 1" - 8 x 5", Gr 5
|
FOR
|
| 34. |
280286
|
[1] |
NUT,1"-8, GB
|
NH
|
| 35. |
47753128
|
[1] |
HYDRAULIC CYLINDER
|
SAS
|
| 36. |
47686587
|
[1] |
|
|
| 37. |
47857856
|
[1] |
PIN
|
SAS
Conveyor
|
| 38. |
7705445
|
[2] |
WASHER,1.62" ID x 3" OD x 0.17" Thk
|
CAS
Superseded by part number: 195-2146
|
| 39. |
47857862
|
[1] |
PIN
|
SAS
|
| 40. |
47857865
|
[1] |
HYDRAULIC CYLINDER
|
SAS
|
| 41. |
9479
|
[1] |
PLUG
|
SAS
|
| 42. |
84313
|
[1] |
ELBOW,45 Degree, 9/16"-18, 37 Degree x 3/4"-16, O-Ring
|
WIN
|
| 43. |
86511191
|
[4] |
WASHER,0.81" ID x 2" OD x 0.15" Thk
|
NH
|
| 44. |
47857864
|
[1] |
PIN
|
SAS
Clevis
|
| 45. |
80708
|
[2] |
COTTER PIN,1/8" x 1 1/2"
|
NH
|
| 46. |
47857863
|
[1] |
PIN
|
SAS
Clevis
|
| 47. |
47866055
|
[1] |
TUBE
|
SAS
|
| 48. |
47879396
|
[1] |
BUSHING
|
SAS
|
| 49. |
47866057
|
[1] |
CLAMP
|
SAS
|
| 50. |
47876148
|
[1] |
STEP
|
SAS
Anti Slip, Black
|
| 51. |
47686556
|
[1] |
ARM
|
SAS
Guide
|
| 52. |
47894230
|
[1] |
BUSHING
|
SAS
|
| 53. |
47686541
|
[1] |
SUPPORT
|
SAS
Arm
|
