| 1. |
47747646
|
[1] |
MOUNT
|
SAS
Manual Auger Black Superseded by part number: 47950744
|
| 2. |
47748034
|
[1] |
ARM
|
SAS
Auger Inner
|
| 3. |
47748035
|
[1] |
ARM
|
SAS
Auger Outer
|
| 4. |
47748037
|
[1] |
ARM
|
SAS
Auger Pivot
|
| 5. |
84262710
|
[1] |
MOUNT
|
SAS
|
| 6. |
47744272
|
[1] |
SUPPORT
|
SAS
Saddle Plate
|
| 7. |
47747698
|
[1] |
PIN
|
SAS
|
| 8. |
23261
|
[2] |
WASHER
|
SAS
1.515 ID 2.25
|
| 9. |
47748281
|
[1] |
TUBE
|
SAS
Spacer
|
| 10. |
47747699
|
[1] |
PIN
|
SAS
31.75 X 197 mm
|
| 11. |
47534143
|
[2] |
U-BOLT,M16 x 2, Square, 180mm W x 175mm L
|
SAS
|
| 12. |
84557601
|
[1] |
PIN,31.75mm OD x 442mm L
|
SAS
|
| 13. |
43168
|
[2] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 14. |
323866
|
[4] |
BOLT,Hex, M16 x 2.0 x 60mm, Cl 8.8
|
NH
Superseded by part number: 120091
|
| 15. |
47748660
|
[2] |
PIN
|
SAS
Auger Arm
|
| 16. |
47748659
|
[1] |
ROD
|
SAS
|
| 17. |
146988
|
[10] |
LOCK NUT,M16 x 2, Cl 8
|
BER
Superseded by part number: 86000441
|
| 18. |
130078
|
[3] |
LOCK PIN,M4 x 30, Slotted
|
COE
Superseded by part number: 14164370
|
| 19. |
4770
|
[1] |
ROLL PIN
|
FLX
.5 x 3 mm
|
| 20. |
87505489
|
[1] |
COMPRESSION SPRING
|
SAS
Harrow Pin
|
| 21. |
86518210
|
[3] |
BOLT,Hex, M14 x 75mm, Cl 8.8
|
BAS
|
| 22. |
412370
|
[3] |
NUT,M14 x 2, Cl 8
|
ZED
|
| 23. |
9706717
|
[2] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
NH
|
| 24. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 25. |
87020818
|
[1] |
LOCK PIN,1/4" OD x 2" OAL, Slotted
|
EML
|
| 26. |
84583373
|
[1] |
SUPPORT
|
SAS
|
| 27. |
87000071
|
[2] |
COMPRESSION SPRING,47.2mm Free Length
|
GI
Superseded by part number: 540815R2
|
| 28. |
47744192
|
[1] |
SUPPORT
|
SAS
Auger Rear Black
|
| 29. |
47744197
|
[1] |
SUPPORT
|
SAS
Rear Black
|
| 30. |
1313
|
[2] |
WASHER,1-1/2" ID x 2-1/4" OD x 10 Ga Thk
|
FLX
Superseded by part number: 81900328
|
| 31. |
80718
|
[1] |
LUBE NIPPLE,1/4"-28 x 90 Degree
|
GI
Superseded by part number: 87415
|
| 32. |
80714
|
[1] |
LUBE NIPPLE,1/4"-28 NPT x .54" lg
|
PA
Superseded by part number: 87414
|
| 33. |
381928
|
[2] |
ROLL PIN,10mm OD x 50mm L, Slotted
|
ZED
|
